Infineon IGBT Module 2 A 16-Pin 20 V DSO-16 1ED020I12FA2XUMA2
Specifications
| Country of Origin | India |
|---|---|
| Brand | Infineon |
| Model | 1ED020I12FA2XUMA2 |
| Output Current | 2A |
| Maximum Operating Temperature | 150°C |
| Package Type | DSO-16 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | DIN EN 60747-5-2 |
| Pin Count | 16 |
| Minimum Supply Voltage | 20V |
| Fall Time | 350ns |
| Driver Type | IGBT |
Key Features
- The module supports an output current of 2 amperes for effective switching.
- It comes in a DSO-16 package with 16 pins, facilitating easy integration.
- The driver type is IGBT, designed for isolated galvanic driver applications.
- Operating voltage is fixed at 20 volts, compatible with 5V CMOS logic input.
- The device operates over a wide temperature range from -40°C to 150°C.
- Fall time is fast at 350 nanoseconds, enabling efficient switching.
- Meets insulation standards DIN EN 60747-5-2 for basic galvanic isolation.
- Features integrated protection and can operate reliably at high ambient temperatures.
Product Description
Infineon 1ED020I12FA2XUMA2 IGBT Module is a galvanically isolated single channel gate driver IC designed within a PG-DSO-16 package. It provides an output current capability of typically 2 A with a fast fall time of 350 ns, making it suitable for various power electronics applications.
The device operates at a fixed supply voltage of 20 V with all input logic pins compatible with 5 V CMOS, allowing direct microcontroller interfacing. Its operating temperature range from -40°C up to 150°C ensures reliable function in harsh environments.
This module offers basic insulation per DIN EN 60747-5-2 with coreless transformer isolation technology. It includes integrated protection features for robust performance and is ideal for industrial, power management, and gate driving electronics.
Electrical characteristics such as a 16-pin DSO packaging and a peak output current of 2 A make it well-suited for efficient IGBT switching and motor control applications. It is commonly used in industrial automation, power inverters, and PWM controllers.
The module supports an output current of 2 amperes for effective switching. It comes in a DSO-16 package with 16 pins, facilitating easy integration. The driver type is IGBT, designed for isolated galvanic driver applications.
Operating voltage is fixed at 20 volts, compatible with 5V CMOS logic input. The device operates over a wide temperature range from -40°C to 150°C. Fall time is fast at 350 nanoseconds, enabling efficient switching. Meets insulation standards DIN EN 60747-5-2 for basic galvanic isolation.
Features integrated protection and can operate reliably at high ambient temperatures. Not certified for automotive standards but suitable for industrial electronics applications.
Infineon gate driver modules like the 1ED020I12FA2XUMA2 play a critical role in power management circuits across construction, manufacturing, HVAC, and laboratory industrial equipment. Its robust insulation and operating range support diverse applications requiring reliable gate drive signals with galvanic isolation.
Explore more electronic semiconductor Gate Drivers at EnvMart for enhanced industrial power control solutions.
