Vishay 60 V 20 A Surface Mount Schottky Rectifier Diode TO-252 Package V20PW60HM3/I
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 13in |
| Brand | Vishay |
| Height | 1.3mm |
| Length | 6.1mm |
| Model | V20PW60HM3/I |
| Width | 5.97mm |
| Mount Type | Surface |
| Series | eSMP |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | RoHS |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 20A |
| Peak Reverse Repetitive Voltage Vrrm | 60V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 70mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 200A |
| Maximum Forward Voltage Vf | 0.66V |
Key Features
- Constructed using Trench MOS Schottky technology for low forward voltage drop.
- Operates at maximum forward current of 20 A and reverse voltage of 60 V.
- Designed with a compact TO-252 surface mount package with 3 pins.
- Features a very low profile height of 1.3 mm suitable for automated PCB placement.
- Operating temperature range from -40°C to 150°C, with high surge current capacity of 200 A.
- Meets AEC-Q101 automotive standard ensuring reliability in automotive applications.
- Low power losses enable high efficiency in DC/DC converters and polarity protection circuits.
- RoHS compliant and suitable for use in high frequency power applications.
Product Description
Vishay V20PW60HM3/I is a high-performance Schottky rectifier diode designed for surface mount applications with a TO-252 package type. Operating at a maximum continuous forward current of 20 A and a peak reverse repetitive voltage of 60 V, this diode features advanced Trench MOS Schottky technology to achieve low forward voltage drop and high efficiency operation.
The device’s low profile height of 1.3 mm and footprint dimensions of 6.1 mm length by 5.97 mm width make it suitable for automated high-density PCB assembly. It is constructed to withstand operation between -40°C and 150°C, allowing for robust performance in diverse industrial and automotive environments.
This diode offers a peak non-repetitive forward surge current rating of 200 A, supporting transient loads without damage. It provides a peak reverse current of merely 70 mA, ensuring reliable switching in power supply circuits. Compliance with the AEC-Q101 standard certifies its suitability for automotive electronics requiring stringent quality and reliability.
Typical applications include low voltage, high frequency DC/DC converters, freewheeling diodes, and polarity protection circuits. Its low forward voltage and power loss characteristics contribute significantly to system efficiency and thermal management.
Uses Trench MOS Schottky technology for efficient operation. Compact TO-252 surface mount package with 3 pins. Maximum continuous forward current of 20 A and reverse voltage 60 V. Wide operating temperature range from -40°C up to 150°C.
Automotive standard AEC-Q101 qualified component. Low forward voltage drop at 0.66 V enhances power efficiency. High surge current capability of 200 A for transient conditions. RoHS compliant for environmentally responsible applications.
Ideal for industrial, automotive, and electronic component manufacturing.
This Vishay component is a reliable, high-quality Schottky diode suitable for integration into a variety of power electronics, semiconductor, and electronic component applications. It offers a robust solution to achieve low losses and high efficiency in demanding environments.
Explore more Vishay Schottky Diodes and rectifiers at EnvMart to find optimal components for your power management and semiconductor requirements.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this diode is 20 A.
The peak reverse repetitive voltage rating is 60 V.
It operates within a temperature range of -40°C to 150°C.
This diode is packaged in a TO-252 surface mount package.
The TO-252 package has 3 pins.
The height of this diode is 1.3 mm.
The maximum forward voltage drop is 0.66 V.
The peak non-repetitive forward surge current rating is 200 A.
Yes, it meets the AEC-Q101 automotive standard and is RoHS compliant.
This diode is suitable for low voltage, high frequency DC/DC converters, freewheeling diodes, and polarity protection circuits.
The peak reverse current is 70 mA.
It is constructed using Trench MOS Schottky technology for low forward voltage drop.
