Wurth Elektronik WR-PHD Series Straight Surface PCB Socket, 4-Contact, 2 Row, 1.27 mm Pitch, 1A, 100V 62300421021

Wurth Elektronik 62300421021 PCB Socket from the WR-PHD Series is a straight, surface mount 4-contact socket with a 2-row, 1.27 mm pitch configuration. It is engineered for board-to-board connections and supports a rated current of 1A with a voltage rating of 100V.

The socket's housing is constructed from durable polyamide (PA9T), providing mechanical stability and resistance to environmental factors. Its copper alloy contacts are gold plated to ensure consistent connectivity and reduce oxidation over long-term use. This component operates effectively over a wide temperature range, from -40°C to +105°C, making it suitable for diverse industrial and electronic environments.

With a compact height of 4.5 mm and a 1.27 mm row pitch, the WR-PHD series socket is optimized for dense electronic assemblies where reliable connection and small form factor are key. The female contact gender design allows for easy mating with pin headers for flexible PCB system configurations.

The socket withstands voltages up to 500V AC, enhancing its insulation and safety standards in demanding conditions. It supports solder termination type and is intended for surface mount applications, which facilitates automated PCB assembly processes.

This product is manufactured in China and does not carry specific approvals or certifications. It is ideal for use in electronic manufacturing, industrial controls, computing equipment, and communications hardware requiring robust board-to-board connector solutions.

The socket's straight orientation simplifies integration in low profile designs. Polyamide housing offers thermal resistance for advanced electronic projects. Gold plated copper alloy contacts minimize electrical resistance and corrosion.

Wide operating temperature range enhances versatility in harsh environments. Designed for solder mounting to solidify electrical and mechanical connection. Supports 1A current and 100V voltage for standard electronic circuit needs.

Compact 1.27 mm pitch suits high density board configurations. 500V AC withstanding voltage ensures safe operation at higher voltages. Female contacts enable compatibility with various male headers and connectors. Explore more products in the PCB Sockets category for diverse electronic component solutions on EnvMart.
