| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 0.6mm |
| Length | 2.5mm |
| Model | PLZ16C-HG3_A/H |
| Mount Type | Surface |
| Series | PLZ |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-219AC (MicroSMF) |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 10mA |
| Maximum Reverse Leakage Current | 200nA |
| Nominal Zener Voltage Vz | 16.51V |
| Zener Type | General Purpose |
| Maximum Zener Impedance | 18Ω |
Vishay PLZ16C-HG3_A/H is a single element silicon planar Zener diode with a nominal Zener voltage of 16.51 V and maximum power dissipation of 500 mW. This general purpose Zener diode is housed in a compact surface mount DO-219AC (MicroSMF) package, offering low profile and suitable for high density circuit boards.
Designed to provide excellent voltage regulation and stability, the diode features a low leakage current of 200 nA and maximum Zener impedance of 18 Ω when tested at a test current of 10 mA. Its wide operating temperature range from -55°C to 150°C ensures reliable operation under demanding industrial environmental conditions.
This diode series is compliant with IEC 61000-4-2 and IEC 61760-1 standards, RoHS compliant, and meets automotive standard AEC-Q101 for enhanced product quality and reliability in automotive semiconductor applications. The ultra small MicroSMF package enables wave and reflow soldering withstood at 260°C, allowing flexible PCB assembly processes.
The Vishay PLZ16C-HG3_A/H is well-suited for use in electronic components, power and connectors, semiconductors in low power voltage regulation, voltage reference circuits, and protection circuits in industrial, automotive, laboratory, and telecommunications fields.
Single diode configuration ensuring steady voltage regulation. Nominal Zener voltage of 16.51 V providing stable voltage reference. Surface mount DO-219AC (MicroSMF) package ideal for compact circuit designs. Maximum power dissipation rated at 500 mW suitable for low-power applications.
Wide operating temperature range from -55°C to 150°C for reliable performance in harsh environments. Low leakage current of 200 nA to enhance circuit efficiency. Maximum Zener impedance of 18 Ω at 10 mA test current for stable operation.
Compliant with IEC 61000-4-2, IEC 61760-1, RoHS standards and automotive grade AEC-Q101 certified. Ultra-small silicon planar diode construction with high temperature soldering capability up to 260°C. Suitable for industrial, automotive, laboratory, and telecommunications applications.
Explore Vishay Zener Diodes and other related semiconductor components on EnvMart for reliable electronic component sourcing.
