TDK Film Capacitor 3.3 nF 700V AC 2 kV DC Through Hole Mount B32672L8332J000

Free Delivery in India | Lowest Global Shipping Charges

TDK Film Capacitor 3.3 nF 700V AC 2 kV DC Through Hole Mount B32672L8332J000



Category Film Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	10.5mm
Length	18mm
Model	B32672L8332J000
Width	5mm
Mount Type	Through Hole
Series	B32672L
Maximum Operating Temperature	125°C
Capacitance	3.3nF
Standards/Approvals	RoHS, UL
Pin Count	2
Rated AC Voltage	700V ac
Rated DC Voltage	2kV dc
Lead Pitch	15mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200 Rev D

Key Features

Metallized polypropylene film construction ensures reliable electrical performance.
Compact dimensions with 18mm length, 10.5mm height, and 5mm width.
Lead pitch of 15mm and lead diameter of 0.8mm for standard through hole PCB mounting.
Rated maximum operating temperature of 125°C for durability in demanding environments.
Complies with RoHS and UL standards ensuring environmental and safety compliance.
Meets automotive standard AEC-Q200 Rev D, suitable for automotive applications.
High peak voltage and current withstand capacity for pulse and high-frequency circuits.
Applications include electronic ballasts, switched mode power supplies, and resonant circuits.

Product Description

TDK B32672L8332J000 film capacitor is a precision metallized polypropylene capacitor with a capacitance of 3.3 nF, designed for high-voltage AC and DC applications. Rated for 700V AC and 2 kV DC, this component features a robust through hole mount style with 2 pins and a 15mm lead pitch. Its compact form factor measuring 18mm in length, 10.5mm in height, and 5mm in width makes it suitable for densely populated circuit boards.

Constructed with epoxy resin sealing, this capacitor offers excellent protection against mechanical and environmental stresses. Its maximum operating temperature of 125°C ensures reliability in industrial and automotive settings. The B32672L series is compliant with strict RoHS and UL certifications, as well as the automotive AEC-Q200 Rev D standard, establishing it as a dependable solution for automotive and high-frequency electronic applications.

The capacitor supports high peak voltage and current pulses, making it ideal for use in electronic ballasts, resonant circuits, and switched mode power supplies. Its small size and advanced film technology allow for efficient performance in pulse circuits under challenging high-frequency conditions. For environmentally sensitive projects, halogen-free variants can be requested.

Metallized polypropylene film dielectric for stable capacitance and low loss. Through hole mount type with 2 pins and 15mm lead pitch for secure PCB attachment. High temperature rating up to 125°C for enhanced reliability in harsh conditions.

Certifications: RoHS, UL, and AEC-Q200 Rev D compliant. Designed for industrial, automotive, and commercial electronics usage. Compact dimensions enable space-saving PCB designs. Suitable for power electronics, switching power supplies, and resonant circuits.

Epoxy resin sealing improves mechanical and environmental resistance. Halogen-free option available to meet environmental standards.

This TDK film capacitor is an essential component for electronic designers requiring stable capacitance and high voltage durability in compact packages. It supports a wide range of industrial and automotive applications, making it a versatile choice in passive component assemblies. Explore related products in the Film Capacitor category at EnvMart for comprehensive electronic component solutions.
