TDK SIMID 1812 Shielded Wirewound Surface Mount Inductor with Ferrite Core 47 μH ±10 % 210 mA Idc Q:30 B82432C1473K000
Specifications
| Country of Origin | Hungary |
|---|---|
| Brand | TDK |
| Height | 3.2mm |
| Length | 4.5mm |
| Model | B82432C1473K000 |
| Depth | 3.2mm |
| Packaging | Tape & Reel |
| Series | SIMID |
| Maximum Operating Temperature | 150°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Ferrite |
| Inductance | 47μH |
| Standards/Approvals | RoHS |
| Package/Case | 1812 |
| Maximum DC Current | 210mA |
| Pin Count | 2 |
| Maximum DC Resistance | 2.3Ω |
| Inductance Tolerance | ±10 % |
| Termination Style | Solder |
| Maximum Self Resonant Frequency | 12MHz |
| Minimum Quality Factor | 30 |
| Inductor Construction | Wirewound |
| Automotive Standard | AEC-Q200 |
Key Features
- Compact 1812 package size suitable for SMT applications.
- Shielded design reduces electromagnetic interference.
- Ferrite core material ensures high performance and stability.
- Operating temperature range from -55°C to 150°C.
- AEC-Q200 automotive standard qualified for reliable use.
- Maximum DC resistance of 2.3 Ω for efficient current flow.
- Maximum self-resonant frequency of 12 MHz supports high frequency operations.
- Minimum quality factor of 30 enhances signal integrity.
Product Description
TDK B82432C1473K000 is a shielded wirewound surface mount inductor featuring a ferrite core, designed for high performance in compact SMT 1812 packaging. The inductor provides a rated inductance of 47 μH with a tolerance of ±10 % and supports a maximum DC current of 210 mA.
This component is manufactured with a solder termination style and enclosed in a moulded case, ensuring mechanical robustness and reliable electrical performance. It complies with RoHS environmental standards and is qualified for automotive applications per the AEC-Q200 standard.
Operating safely across a temperature range of -55°C to 150°C, it offers a maximum DC resistance of 2.3 Ω and a maximum self-resonant frequency of 12 MHz. The minimum quality factor of 30 facilitates efficient filtering and signal tuning operations.
The B82432C1473K000 series is ideal for applications such as filtering supply voltages, coupling and decoupling, antenna systems, automotive electronics, telecommunications, and various industrial electronics where size, shielding, and stable inductance are critical.
Packaged on tape and reel, this inductor supports high volume automated PCB assembly processes, ensuring efficiency and precision in manufacturing. Compact 1812 surface mount package size designed for high-density PCB layouts.
Shielded wirewound construction reduces EMI and enhances signal quality. Ferrite core for stable inductance and temperature tolerance. Designed to meet stringent automotive and industrial standards. Suitable for filtering, coupling, decoupling, and antenna applications.
Explore the full range of Surface Mount Inductors and other electronic components at EnvMart for industrial-grade quality and reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The inductance value of this inductor is 47 μH with a tolerance of ±10%.
This model supports a maximum DC current of 210 mA.
It operates safely across a temperature range of -55°C to 150°C.
The maximum DC resistance is 2.3 Ω, which allows for efficient current flow.
The maximum self-resonant frequency is 12 MHz, supporting high frequency operations.
The minimum quality factor is 30, which enhances signal integrity.
This inductor comes in a compact 1812 package size, suitable for high-density PCB layouts.
It features a ferrite core material, ensuring high performance and stability.
Yes, it is qualified for automotive applications per the AEC-Q200 standard.
The termination style is solder, which is standard for surface mount components.
It is packaged on tape and reel, facilitating high volume automated PCB assembly processes.
This model complies with RoHS environmental standards.
