onsemi NPN Power Transistor, 4 A Collector Current, 100 V DC Voltage, Surface Mount TO-252 3-Pin MJD243T4G

Name: onsemi NPN Power Transistor, 4 A Collector Current, 100 V DC Voltage, Surface Mount TO-252 3-Pin MJD243T4G
Brand: onsemi
SKU: 106350



Category Bipolar Transistors Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	2.38mm
Length	10.41mm
Model	MJD243T4G
Width	6.73mm
Mount Type	Surface
Maximum Operating Temperature	150°C
Package Type	TO-252
Minimum Operating Temperature	-65°C
Pin Count	3
Maximum Collector Emitter Voltage Vceo	100V dc
Minimum DC Current Gain hFE	15
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	7V
Maximum Collector Base Voltage VCBO	100V dc
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	12.5W
Maximum DC Collector Current Idc	4A
Transistor Configuration	Single
Maximum Transition Frequency ft	10MHz

Key Features

Single transistor configuration in TO-252 package ensuring compact size.
Maximum power dissipation of 12.5 watts for efficient thermal handling.
Operates at temperatures ranging from -65°C to 150°C for reliable performance.
Minimum DC current gain of 15 ensuring good amplification properties.
Pin count of 3 with a surface mount type suitable for PCB assemblies.
Automotive qualified meeting AEC-Q101 standard for high reliability.
Maximum transition frequency of 10 MHz suitable for moderate frequency switching.
Polarity is NPN suitable for power switching and amplification.

Product Description

onsemi MJD243T4G is a single NPN power transistor designed primarily for surface mount applications using a TO-252 3-pin DPAK package. It provides a maximum DC collector current of 4 A and can handle collector-emitter voltages up to 100 V DC, making it suitable for a variety of automotive and industrial power switching applications.

The transistor is capable of dissipating up to 12.5 W of power while maintaining stable operation across a wide temperature range from -65°C to 150°C. It features a minimum DC current gain (hFE) of 15 and supports switching frequencies up to 10 MHz, allowing moderate speed performance required in many electronic designs.

Mechanically, this device measures 10.41 mm in length, 6.73 mm in width, and 2.38 mm in height, facilitating compact, efficient PCB mounting. Compliant with the AEC-Q101 automotive standard, it ensures reliable and consistent operation under stringent automotive environmental conditions.

Applications for this transistor include automotive electronics, power management systems, and general industrial control circuitry requiring efficient amplification and switching. Its surface mount design and pin configuration simplify automation and high-volume manufacturing processes.

Single transistor configuration in TO-252 package ensuring compact size. Maximum power dissipation of 12.5 watts for efficient thermal handling. Operates at temperatures ranging from -65°C to 150°C for reliable performance.

Minimum DC current gain of 15 ensuring good amplification properties. Pin count of 3 with a surface mount type suitable for PCB assemblies. Automotive qualified meeting AEC-Q101 standard for high reliability. Maximum transition frequency of 10 MHz suitable for moderate frequency switching.

Compact dimensions: Length 10.41 mm, Width 6.73 mm, Height 2.38 mm. NPN polarity for power switching and amplification applications.

This transistor is ideal for industrial electronics, automotive systems, power amplification, and embedded control systems. Discover a broad range of bipolars and power transistors in the EnvMart semiconductor catalog for your precise engineering needs.
