Samtec SSQ Series 6-Contact 1 Row 2.54 mm Pitch Straight Through Hole PCB Socket SSQ-106-01-F-S

Samtec SSQ-106-01-F-S is a premium SSQ Series straight through hole PCB socket designed for robust electronic component interconnections. It supports 6 contacts in a single row configuration with a precise 2.54 mm pitch, facilitating reliable board-to-board connections in various electronic assemblies.

This socket features a housing made from liquid crystal polymer, providing outstanding mechanical strength and heat resistance suitable for industrial and commercial applications. The contacts are crafted from phosphor bronze and plated with gold, which enhances conductivity and corrosion resistance, ensuring long-lasting electrical performance.

Designed to support a current rating of 6.3 A per pin (with 2 pins powered) and voltage up to 655 V, the SSQ-106-01-F-S is suitable for a wide range of electronic circuits requiring dependable power and signal transfer. The Tiger Buy™ contact system provides consistent normal force around 125 grams (4.4 N) that maintains secure connections even in demanding environments.

The device operates effectively over a temperature range from -55°C to 125°C, making it fit for harsh conditions often encountered in industrial, manufacturing, laboratory, and electronics assembly environments. It supports up to 100 mating cycles with premium gold plating, ensuring durability and reusability.

Termination is via solder on a through-hole mount, simplifying installation on printed circuit boards. The connector system is designed for board-to-board connectivity, featuring female contact gender and a square tail sub-type for optimal soldering properties.

Liquid Crystal Polymer housing assures robust heat and mechanical resistance. Phosphor Bronze gold-plated contacts enhance conductivity and corrosion resistance. Rated for 6.3 A current per pin and 655 V maximum voltage.

Supports industrial temperature range from -55°C to 125°C. Tiger Buy™ contact system provides reliable normal force for secure connections. 100 mating cycles supported with 10μ” gold plating durability. Through hole solder termination ensures reliable PCB mounting.

Suitable for board-to-board electronic systems with female contacts.

This socket is ideal for electronics manufacturing, industrial equipment, laboratory instrumentation, and other applications where dependable PCB connectivity is essential. It fulfills industry requirements for durability, electrical safety, and mechanical strength.
