onsemi CMOS Inverter 6 Elements, 14-Pin SOIC MM74HC04MX

onsemi MM74HC04MX CMOS Inverter 6 Elements, 14-Pin SOIC is a high-speed CMOS logic device designed for signal inversion with low power consumption and compatibility with various digital logic circuits. It operates over a wide voltage range of 2V to 6V and withstands industrial operating temperatures from -40°C to 85°C, making it suitable for robust electronic applications.

This device contains six independent inverter gates within a single SOIC 14-pin surface mount package, enabling space-efficient designs and simplifying logic circuit implementation. Its maximum propagation delay time of 145 nanoseconds delivers rapid switching performance, essential for timing-critical applications.

The MM74HC04MX supports input CMOS and LSTTL output logic levels, facilitating integration in mixed-signal environments. It features characteristic HC series logic family traits and does not incorporate Schmitt trigger inputs. The maximum supply voltage of 6 volts allows operation in low voltage power systems.

Physically, the device measures 8.75 mm in length, 4 mm in width and 1.5 mm in height, optimized for modern PCB layouts. Maximum output currents are -5.2 mA (high level) and 5.2 mA (low level), ensuring ample drive capabilities for downstream circuitry. It does not hold any specific standards or automotive certifications.

Contains 6 inverter elements per chip for efficient logic inversion. Operates within temperature range -40°C to 85°C for reliable performance. Maximum propagation delay time of 145ns ensures fast switching. Surface mount type with SOIC 14-pin package for PCB assembly.

Maximum supply voltage of 6V suitable for low voltage applications. Compatible with input CMOS and output LSTTL logic levels. Compact dimensions: length 8.75mm, width 4mm, height 1.5mm. Maximum high-level output current of -5.2mA and low-level output current 5.2mA.

Belongs to the HC logic family with no Schmitt trigger input.

This CMOS inverter is ideal for industrial electronics, embedded systems, logic circuit designs, and automotive electronics where reliable, fast logic inversion is required. It is suitable for applications in consumer electronics, automation systems, communication devices, and computer peripherals.
