Nexperia N-Channel MOSFET, 3A, 100V, Enhancement Mode, SC-73, Surface Mount, 4-Pin, PHT6NQ10T,135
Specifications
| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 1.7mm |
| Length | 6.7mm |
| Model | PHT6NQ10T,135 |
| Width | 3.7mm |
| Mount Type | Surface |
| Series | PHT6NQ10T |
| Maximum Operating Temperature | 150°C |
| Package Type | SC-73 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 4 |
| Channel Type | Type N |
| Maximum Continuous Drain Current Id | 3A |
| Maximum Drain Source Voltage Vds | 100V |
| Maximum Drain Source Resistance Rds | 90mΩ |
| Channel Mode | Enhancement |
| Maximum Power Dissipation Pd | 1.8W |
| Typical Gate Charge Qg @ Vgs | 21nC |
| Maximum Gate Source Voltage Vgs | 20V |
| Forward Voltage Vf | 1.1V |
| N-Channel MOSFET, 2.6 A, 55 V, 4-Pin SC-73 NXP BUK98150-55,135Brand | NXP |
Key Features
- High-power N-channel MOSFET for efficient switching and amplification applications.
- Enhancement mode for precise control with low on-resistance of 90 mΩ.
- Surface mount SC-73 package provides space-saving integration for PCBs.
- Maximum power dissipation of 1.8 W ensures robust performance in demanding environments.
- Operates across wide temperature range from -65°C to 150°C.
- Supports gate voltage up to 20 V and typical gate charge of 21 nC.
- Compact design with 6.7mm length, 3.7mm width, and 1.7mm height.
- Suitable for industrial, automotive, and power electronics applications.
Product Description
Nexperia PHT6NQ10T,135 is a high-quality N-channel enhancement mode MOSFET designed for demanding power electronics and switching applications. With its robust maximum drain-source voltage of 100 V and a continuous drain current rating of 3 A, this device enables efficient operation in compact and high-density electronic assemblies.
The SC-73 surface mount package with 4 pins allows for space-saving integration on densely populated printed circuit boards, making it suitable for modern electronic designs. Its enhancement mode operation ensures precise control and fast switching, while the low maximum drain-source resistance of 90 mΩ minimizes power loss during conduction.
This MOSFET features a maximum power dissipation of 1.8 W, which allows reliable operation under heavy loads and thermal stresses. With a wide operating temperature range from -65°C to 150°C, it offers dependable performance in industrial, laboratory, and automotive environments.
Electrical characteristics include a maximum gate-source voltage of 20 V, a typical gate charge of 21 nC for fast switching, and a forward voltage of 1.1 V. The compact dimensions (6.7mm in length, 3.7mm in width, and 1.7mm in height), along with its 4-pin SC-73 package, make it ideal for designs requiring high power density.
Applications span industrial power supplies, motor control, energy management systems, automotive electronics, and laboratory instrumentation. The device’s enhancement mode and space-efficient surface mount form factor make it a strong choice for engineers seeking reliability and performance.
High continuous drain current capability supports demanding circuit requirements. Low on-resistance improves energy efficiency and reduces heat generation. Wide temperature tolerance enables use in harsh or variable operating conditions.
Surface-mount SC-73 design facilitates automated manufacturing and compact layout. Gate charge and voltage characteristics suited for fast switching circuits. Explore more Nexperia semiconductors and MOSFETs at EnvMart for optimized circuit solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous drain current for this model is 3 A.
This MOSFET has a maximum drain-source voltage rating of 100 V.
The maximum drain-source resistance is 90 mΩ, which helps minimize power loss during conduction.
It operates across a wide temperature range from -65°C to 150°C.
The typical gate charge is 21 nC, suitable for fast switching applications.
The SC-73 package dimensions are 6.7 mm in length, 3.7 mm in width, and 1.7 mm in height.
The maximum power dissipation is 1.8 W, allowing reliable operation under heavy loads.
The maximum gate-source voltage is 20 V.
This model is suitable for industrial power supplies, motor control, energy management systems, automotive electronics, and laboratory instrumentation.
The SC-73 package has 4 pins.
This model is an N-channel enhancement mode MOSFET.
The country of origin for this MOSFET is India.
