Nexperia PNP Transistor -100 mA, -45 V, 3-Pin SOT-23 BC857A,215

Free Delivery in India | Lowest Global Shipping Charges

Nexperia PNP Transistor -100 mA, -45 V, 3-Pin SOT-23 BC857A,215

Name: Nexperia PNP Transistor -100 mA, -45 V, 3-Pin SOT-23 BC857A,215
Brand: Nexperia
SKU: 414555
Price: 0.02 USD
Availability: InStock



Category Bipolar Transistors Brand Nexperia Condition New

Specifications

Country of Origin	India
Brand	Nexperia
Height	1mm
Length	2.9mm
Model	BC857A,215
Width	1.3mm
Mount Type	Surface
Series	BC857
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-65°C
Standards/Approvals	RoHS
Pin Count	3
Maximum Collector Emitter Voltage Vceo	-45V
Minimum DC Current Gain hFE	125
Transistor Polarity	PNP
Maximum Emitter Base Voltage VEBO	-5V
Maximum Collector Base Voltage VCBO	-50V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	250mW
Maximum DC Collector Current Idc	-100mA
Transistor Configuration	Single
Maximum Transition Frequency ft	100MHz
onsemi BC857ALT1G Transistor, -100 mA PNP, -45 V, 3-Pin SOT-23Brand	onsemi

Key Features

This transistor offers a maximum power dissipation of 250 mW suitable for low power circuits.
It has a minimum DC current gain (hFE) of 125 ensuring effective amplification performance.
The maximum operating temperature is 150°C, making it suitable for a range of environments.
The device is AEC-Q101 qualified, ensuring reliability for automotive applications.
Its Ultra-Small 1.3 mm width and 2.9 mm length SOT-23 surface mount package minimizes PCB space usage.
Supports a broad frequency response up to 100 MHz for high-speed applications.
Compliant with RoHS standards providing eco-friendly electronics manufacturing.

Product Description

Nexperia BC857A,215 PNP Transistor is a compact and highly reliable bipolar transistor tailored for switching and amplification in electronic circuits. It supports a maximum DC collector current of 100 mA and a voltage rating up to 45 V, making it suitable for low voltage and low power applications.

The transistor is housed in a small footprint 3-pin SOT-23 surface mount package with dimensions of 2.9 mm length, 1.3 mm width, and 1 mm height. Its design focuses on space-saving solutions for compact and high-density PCB layouts.

This device features a minimum DC current gain (hFE) of 125 and a maximum transition frequency (ft) of 100 MHz, ensuring solid performance in amplification and switching circuits. It withstands maximum power dissipation of 250 mW and operates reliably in temperatures ranging from -65°C to 150°C.

Manufactured under RoHS compliant processes and qualified to the automotive standard AEC-Q101, this PNP transistor is ideal for automotive electronics, industrial controls, consumer electronics, and communications applications.

Maximum collector current of 100 mA. Collector emitter voltage rating of 45 V. Small SOT-23 3-pin package for surface mounting. High current gain and transition frequency for effective amplification. Wide operating temperature range for demanding environments.

AEC-Q101 automotive qualification ensuring high reliability. RoHS compliant for environmentally responsible usage.

Nexperia transistors from the BC857 series provide a robust choice for engineers designing compact, efficient, and reliable electronic switching and amplification circuits in industrial, automotive, and consumer product sectors. Explore more from Nexperia's extensive range on EnvMart for professional-grade semiconductor components.
