Epson 8MHz XO Oscillator ±25 ppm CMOS 4-Pin Surface Mount SG-210 STF X1G004171001512

Free Delivery in India | Lowest Global Shipping Charges

Epson 8MHz XO Oscillator ±25 ppm CMOS 4-Pin Surface Mount SG-210 STF X1G004171001512

Name: Epson 8MHz XO Oscillator ±25 ppm CMOS 4-Pin Surface Mount SG-210 STF X1G004171001512
Brand: Epson
SKU: 412177
Price: 2.63 USD
Availability: InStock



Category Oscillator Brand Epson Condition New

Specifications

Country of Origin	India
Brand	Epson
Height	0.8mm
Length	2.5mm
Model	X1G004171001512
Width	2mm
Mount Type	Surface
Series	SG-210 STF
Maximum Operating Temperature	105°C
Output Frequency	8MHz
Minimum Operating Temperature	-40°C
Standards/Approvals	EU RoHS, ISO/TS 16949, ISO 14001, ISO9001, Pb Free
Pin Count	4
Maximum Supply Voltage	3.6V
Minimum Supply Voltage	1.6V
Load Capacitance	15pF
Oscillator Type	XO
Output Level	CMOS

Key Features

8MHz output frequency with ±25 ppm frequency stability for precise timing.
CMOS output level for low power and noise performance.
Surface mount type with compact 2.5 x 2.0 mm package dimensions.
Wide operating voltage range from 1.6V to 3.6V for versatile applications.
Operating temperature from -40°C to 105°C suitable for harsh environments.
Low load capacitance of 15pF ensuring signal integrity.
Compliant with EU RoHS, ISO/TS 16949, ISO 14001, and ISO 9001 standards.
Ideal for industrial, electronic components, automotive, and manufacturing uses.

Product Description

Epson X1G004171001512 8MHz XO Oscillator is a high precision crystal oscillator featuring ±25 ppm frequency stability and CMOS output in a 4-pin surface mount package. It operates from a voltage range of 1.6V to 3.6V and is designed for reliable performance across a temperature range of -40°C to 105°C, making it suitable for industrial and automotive applications.

The oscillator has a low load capacitance of 15pF and a compact 2.5 x 2.0 mm ceramic case size, providing excellent phase noise characteristics and low current consumption. This makes it ideal for embedded system designs, telecommunications, and manufacturing equipment where precise timing signals are crucial.

Manufactured with adherence to stringent standards including EU RoHS, ISO/TS 16949, ISO 14001, and ISO 9001, this SG-210 STF series oscillator ensures both environmental safety and quality assurance. It supports surface mounting on PCB boards with a 4-pin configuration, facilitating easy integration into electronic circuits.

Use cases include instrumentation, communication devices, automotive electronics, and industrial control systems. The device's wide temperature range and stable frequency output ensure reliable operation in demanding environments. The oscillator is RoHS compliant and Pb free, emphasizing eco-friendly manufacturing processes.

8MHz output frequency with ±25 ppm frequency stability for precise timing. CMOS output level for low power and noise performance. Surface mount type with compact 2.5 x 2.0 mm package dimensions. Wide operating voltage range from 1.6V to 3.6V for versatile applications.

Operating temperature from -40°C to 105°C suitable for harsh environments. Low load capacitance of 15pF ensuring signal integrity. Compliant with EU RoHS, ISO/TS 16949, ISO 14001, and ISO 9001 standards. Ideal for industrial, electronic components, automotive, and manufacturing uses.
