Epson 16 MHz Crystal Unit FA-238 Surface Mount 4-Pin 3.2 x 2.5 x 0.7 mm ±50 ppm Q22FA2380013312

Epson Q22FA2380013312 is a 16 MHz crystal unit from the FA-238 series designed for surface mount applications. This miniature SMD crystal features a standard frequency of 16 MHz, with an overtone order set to fundamental for stable and precise frequency control with a tolerance of ±50 ppm.

The crystal unit is housed in a compact FA-238 ceramic package measuring 3.2 mm in length, 2.5 mm in width, and 0.7 mm in height. It utilizes a 4-pin configuration optimized for PCB mounting, providing secure mechanical and electrical connections.

Designed to operate reliably within a temperature range of -40°C to 85°C, it features a load capacitance of 12 pF and series resistance of 80 Ω, delivering consistent performance suited for demanding electronic environments.

This crystal unit complies with environmental standards REACH and RoHS, making it an ideal choice for modern electronic devices such as mobile phones, Bluetooth modules, WLAN ISM band radios, and as clock sources for microprocessor units (MPUs).

Operates at a frequency of 16 MHz with fundamental overtone order. Compact FA-238 surface mount package with 4 pins ensures space-saving PCB integration. Dimensions: 3.2 mm length x 2.5 mm width x 0.7 mm height. Load capacitance of 12 pF for stable oscillation.

Operating temperature range from -40°C to 85°C for versatile usage. Series resistance of 80 Ω enhances signal quality and stability. Compliant with REACH and RoHS environmental standards. Suitable for mobile phones, Bluetooth, WLAN ISM band radio, and MPU clock applications.

This Crystal Unit is essential in various industrial and commercial electronic designs requiring precise frequency control. Browse more components and electronics solutions to find the ideal parts for your technical requirements.
