Panasonic Surface Mount Film Capacitor 1 nF 50 V DC 50 V AC Compact Design ECHU1H102JX5

Panasonic ECHU1H102JX5 is a high-quality surface mount film capacitor with a capacitance of 1 nF, rated at 50 V DC and 50 V AC. Constructed from stacked metallised PPS film, this capacitor features a mould-less design that ensures reliability and consistent performance. It is suitable for applications in electronic circuits requiring stable time constants, oscillation, resonance, filtering, and audio signal processing.

The capacitor supports a maximum operating temperature of 125°C and can reliably withstand conditions of 85°C at 85% relative humidity with a voltage stress of W.V. x 1.0 for 500 hours, making it suitable for use in demanding industrial and electronic applications.

Designed specifically for surface mount technology (SMT), it is compatible with reflow soldering techniques, providing ease of assembly on printed circuit boards with high precision and compact footprints. This makes it ideal for modern compact electronic devices where space and reliability are critical.

The dimensions of the capacitor are 2 mm in length, 1.25 mm width, and 0.9 mm height, facilitating installation in densely packed circuit boards. Its low Equivalent Series Resistance (ESR) contributes to high efficiency and minimal signal loss in filtering and audio circuits.

Panasonic ECHU(X) series capacitors comply with the RoHS directive, ensuring environmentally safe manufacturing and disposal.

This product is manufactured in Japan and guaranteed new, ensuring top quality and performance for industrial, manufacturing, electronics design, and research laboratory applications.

Compact design ideal for time-constant applications, oscillation, and resonance circuits. Constructed from stacked metallised PPS film with mould-less construction for improved reliability. Rated for maximum operating temperature of 125°C ensuring durability in harsh environments.

Surface mount type designed for reflow soldering processes enhancing assembly efficiency. Low Equivalent Series Resistance (ESR) suitable for filtering and audio circuits. Dimensions: 2 mm length, 1.25 mm width, and 0.9 mm height for compact PCB layouts.

Conforms to RoHS standards ensuring compliance with environmental regulations.
