ams OSRAM Infrared Photodiode, ± 60 ° Angle of Half Sensitivity, Through Hole T-1 3/4 Package Type SFH 205 FA

ams OSRAM SFH 205 FA Infrared Photodiode is a precision electronic semiconductor device designed for infrared light detection in diverse electronic applications. Featuring a through-hole T-1 3/4 package and a ± 60 ° angle of half sensitivity, this photodiode offers an effective means to capture infrared signals, making it suitable for use in sensor systems, optical telecommunication, and industrial automation.

The photodiode is sensitive to wavelengths ranging from 740nm to 1100nm, with a peak sensitivity at 900nm, ensuring excellent performance in detecting near-infrared emissions. It features a typical rise and fall time of 20 nanoseconds, enabling fast response times essential for dynamic detection scenarios.

Robust operational temperature limits from -40°C to 100°C allow the SFH 205 FA to function reliably in both extreme cold and elevated temperature environments, making it an ideal choice for industrial and commercial use cases.

The device has a compact footprint with nominal dimensions of 6.9mm in height, 6.3mm in width, and 5.1mm in length, packaged in a standard through-hole format with two pins for straightforward PCB mounting and integration into electronic assemblies.

The photodiode exhibits a breakdown voltage of 32 volts and an open circuit voltage capacity of 330 volts, providing stable performance across wide voltage ranges. It maintains low dark current levels at 2nA, minimizing electrical noise for high accuracy sensing.

This model operates with forward polarity and is not amplified, suitable for applications requiring a direct photodiode sensor without internal gain. Moreover, the SFH 205 FA is RoHS compliant, ensuring it meets environmental directives for safe electronic manufacturing and disposal.

Applications of this infrared photodiode span industrial automation, laboratory instrumentation, sensor arrays, and optical communication systems where reliable infrared detection is critical. Its through-hole mounting type is optimal for prototyping and manufacturing processes requiring manual or automated insertion.

Detects infrared spectrum ranging from 740nm to 1100nm wavelength. Fast response time with 20ns rise and fall times for dynamic detection. Wide operating temperature range from -40°C to 100°C. Compact T-1 3/4 through-hole package with 2 pins for easy mounting.

Breakdown voltage of 32V and open circuit voltage of 330V ensure robust operation. Low dark current of 2nA reduces noise interference for sensitive applications. Forward polarity without amplification for straightforward integration.

RoHS compliant meeting environmental safety standards.
