Panasonic ECQE(F) Polyester Film Capacitor 33 nF 630V AC/DC Through Hole ECQE6333JF
Specifications
| Country of Origin | India |
|---|---|
| Brand | Panasonic |
| Height | 11.9mm |
| Length | 12mm |
| Model | ECQE6333JF |
| Width | 6mm |
| Mount Type | Through Hole |
| Series | ECQE(F) |
| Maximum Operating Temperature | 105°C |
| Capacitance | 33nF |
| Rated AC Voltage | 630V ac |
| Rated DC Voltage | 630V dc |
| Lead Pitch | 10mm |
| Lead Diameter | 0.6mm |
| Automotive Standard | AEC-Q200 |
Key Features
- Capacitance rating of 33 nF for precise capacitance requirements.
- Rated for both 630V AC and 630V DC voltage applications.
- Constructed with flame retardant epoxy resin coating and metallised polyester film for high reliability.
- Complies with automotive standard AEC-Q200 ensuring suitability in automotive environments.
- Designed with a lead pitch of 10mm for standard PCB mounting.
- Maximum operating temperature rated at 105°C for robust performance.
- Compact size with dimensions 12mm length, 11.9mm height, and 6mm width.
- Leads measure 0.6mm in diameter ensuring compatibility with through hole mounting.
Product Description
Panasonic ECQE6333JF is a polyester film capacitor with a capacitance of 33 nF and voltage ratings of 630V AC and 630V DC. This through hole mounted component features a metallised polyester film construction with a flame retardant epoxy resin coating, ensuring high safety and durability in demanding applications.
The capacitor is designed for general purpose use with excellent electrical characteristics owing to its non-inductive, self-healing properties. Its compact dimensions of 12mm length, 11.9mm height, and 6mm width, combined with a 10mm lead pitch and 0.6mm lead diameter, facilitate easy PCB mounting in a variety of circuits.
Meeting automotive standard AEC-Q200, the ECQE(F) series capacitors are suited for automotive and industrial environments where reliability and temperature resilience are critical. The maximum operating temperature of 105°C ensures stable performance under higher thermal loads.
The product complies with international safety standards UL 60384-14, EN 60384-14, and CSA E60384-14, highlighting its quality and safety for global markets. Typical applications include general purpose electronics where stable, reliable film capacitors with high voltage and temperature ratings are required.
Capacitance rating of 33 nF for wide electronic uses. Rated AC voltage of 630V and DC voltage of 630V. Manufactured with flame retardant epoxy resin coating for safety. Metallised polyester film provides self-healing and electrical stability.
Designed for through hole mounting with 10mm lead pitch. Certified to automotive AEC-Q200 and multiple international standards. Compact size with 12mm length, 11.9mm height, and 6mm width. Lead diameter of 0.6mm suitable for standard PCB holes.
Maximum operating temperature of 105°C ensures durability. Ideal for automotive, electronic component manufacturing, industrial, and general-purpose applications. Explore more Film Capacitors and electronic components in our extensive collection at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance rating of this model is 33 nF, suitable for precise capacitance requirements in various electronic applications.
It is rated for both 630V AC and 630V DC voltage applications, making it versatile for different circuit requirements.
This unit has compact dimensions of 12mm in length, 11.9mm in height, and 6mm in width, facilitating easy integration into PCB designs.
The maximum operating temperature is rated at 105°C, ensuring stable performance under higher thermal loads.
It features a lead pitch of 10mm and a lead diameter of 0.6mm, which are standard for through hole mounting on PCBs.
Yes, it complies with the automotive standard AEC-Q200, ensuring suitability for automotive environments.
It is constructed with a metallised polyester film and coated with flame retardant epoxy resin, providing high reliability.
This model is suitable for general purpose electronics, automotive applications, and industrial environments where reliability is critical.
It complies with international safety standards UL 60384-14, EN 60384-14, and CSA E60384-14, highlighting its quality and safety for global markets.
The metallised polyester film construction provides self-healing properties, enhancing electrical stability and reliability.
It is designed for through hole mounting, making it easy to install in various electronic circuits.
This model belongs to the ECQE(F) series of film capacitors, which are known for their reliability in demanding applications.
