Vega VEGAMET 862 Series Level Controller Wall Mount 230V 5A Analogue Output CR - 222 22A
Specifications
| Country of Origin | Germany |
|---|---|
| Voltage | Input 230V-Rated Analogue RS Stock No |
| Brand | Vega |
| Model | CR - 222 22A |
| IP Rating | IP65 |
| Mount Type | Wall |
| Overall Length | 200mm |
| Current Rating | 5A |
| Number of inputs | 2 |
| Output type | Analogue |
| Series | VEGAMET 862 |
| Overall Width | 136mm |
| Input Type | Voltage |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -40°C |
| Number of outputs | 9 |
| Terminal type | M20 |
| Standards/Approvals | cULus, EAC, CE, UL |
| Maximum Supply Voltage | 230V |
| Overall Depth | 76mm |
| Probe Voltage | 27V |
Key Features
- The controller supports 2 voltage inputs and processes signals from 4 to 20 mA or HART sensors.
- Equipped with a large, easy-to-read display suitable for tough field conditions and visibility in sunlight and darkness.
- Designed to operate in ambient temperatures from -40°C to +60°C ensuring reliable performance under extreme conditions.
- Features a wall mount type with M20 terminal type and robust IP65 rating for dust and water protection.
- Supports 9 outputs with a current rating of 5A and provides analogue output signals for integration with control systems.
- Standards compliance includes cULus, EAC, CE, and UL certifications.
- The device measures 200 mm length, 136 mm width, and 76 mm depth, making installation compact and seamless.
- Manufactured in Germany with high quality and industrial-grade construction.
Product Description
Vega CR - 222 22A VEGAMET 862 Series Level Controller Wall Mount is a high-performance measurement and control device intended for industrial automation and process control applications. It features a 230V input voltage rating and an analogue output suitable for integration with existing control systems.
This controller is compatible with 4 to 20 mA and HART sensors, processing measured values and displaying them on a large, easily readable screen, which remains visible under both sunlight and dark conditions. The construction suits harsh environments, offering an IP65 rating for protection against dust and water ingress.
Designed for demanding ambient temperature conditions ranging from -40°C to 60°C, it ensures dependable operation in diverse industrial environments such as manufacturing plants, water treatment facilities, chemical processing, and HVAC systems.
With 2 inputs, 9 outputs, and a 5A current rating, it can manage multiple signal lines and complex control scenarios. The device is wall mountable with M20 terminal type connectors facilitating secure electrical connections. The compact dimensions of 200 mm length, 136 mm width, and 76 mm depth allow for easy installation within control panels or instrumentation rooms.
Manufactured in Germany, the VEGAMET 862 series meets stringent quality standards and carries certifications including cULus, EAC, CE, and UL, enhancing the reliability and safety of installations.
The controller supports 2 voltage inputs for precise level sensing. Large, integrated display ensures clear visualization of data on site. Robust construction with IP65 rating for protection in harsh environments. Wide operating temperature range from -40°C to +60°C.
Features 9 analogue outputs and a 5A current rating for versatile control options. Compact wall mount design measuring 200 x 136 x 76 mm. Compliance with international standards cULus, EAC, CE, and UL certifications. Explore the Vega range for reliable industrial level controller solutions suitable for process automation and measurement needs.
Explore more products in our Level Controllers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage rating of this model is 230V.
It operates effectively in ambient temperatures ranging from -40°C to +60°C.
This controller features 2 voltage inputs and 9 analogue outputs.
It has an IP65 rating, providing protection against dust and water ingress.
The outputs have a current rating of 5A.
It is compatible with 4 to 20 mA and HART sensors.
The dimensions are 200 mm in length, 136 mm in width, and 76 mm in depth.
It uses M20 terminal type connectors for secure electrical connections.
It complies with cULus, EAC, CE, and UL certifications.
Yes, it features a large, easy-to-read display that remains visible in both sunlight and darkness.
It is manufactured in Germany.
The output type is analogue, suitable for integration with control systems.
