Wurth Elektronik Right Angle Through Hole PCB Header 14 Contacts 4.2 mm Pitch 2 Row Shrouded MPC4

Name: Wurth Elektronik Right Angle Through Hole PCB Header 14 Contacts 4.2 mm Pitch 2 Row Shrouded MPC4
Brand: Wurth Elektronik
SKU: 403245
Price: 2.27 USD
Availability: InStock



Category PCB Header Brand Wurth Elektronik Condition New

Specifications

Country of Origin	Taiwan
Voltage	600V
Brand	Wurth Elektronik
Orientation	Right Angle
Current	6A
Model	MPC4
Mount Type	Through Hole
Housing Material	Polyamide
Contact Material	Tin Over Nickel
Series	WR-MPC4
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	4.2mm
Standards/Approvals	RoHS, UL E323964
Contact Plating	Tin
Number of Contacts	14
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Tail Pin Length	25.2mm

Key Features

Features a dual row configuration with 14 male contacts for secure connectivity.
Constructed with polyamide housing ensuring insulation and durability.
Supports current rating up to 6A and voltage up to 600V for industrial applications.
Right angle orientation suitable for space-efficient PCB layouts.
Contacts are tin plated over nickel ensuring corrosion resistance and solderability.
Tail pin length of 25.2 mm compatible with through-hole mounting.
Operating temperature range from -40°C to 105°C suitable for harsh environments.
Complies with RoHS and UL E323964 certifications ensuring quality and regulatory compliance.

Product Description

Wurth Elektronik MPC4 Series Right Angle Through Hole PCB Header is designed for industrial and commercial electronics where durable and reliable wire-to-board connections are essential. The shrouded connector system includes 14 male contacts arrayed in two rows with a 4.2 mm pitch to provide stable signal and power transmission.

This PCB header features a polyamide (PA66) housing that resists heat and electrical stresses, suitable for demanding environments with operating temperatures from -40°C up to 105°C. The tin over nickel contact plating enhances corrosion resistance and soldering performance, assuring long-lasting connections on printed circuit boards.

With a rated current of 6A and voltage rating of 600V, this right angle PCB header is ideal for power and electronic components integration in various industrial control, automation, and manufacturing equipment.

The through hole mounting style includes tail pins 25.2 mm in length for secure mechanical and electrical attachment to PCB substrates. This connector complies with RoHS and UL E323964 standards, ensuring that it meets stringent safety and environmental regulations.

Dual row, 14 contact configuration maximizes connectivity in a compact footprint. Durable polyamide housing provides excellent insulation and mechanical strength. Shrouded design minimizes pin damage and misalignment during assembly.

Right angle orientation facilitates optimized PCB layout and space utilization. Tin over nickel plating on contacts ensures reliable electrical performance and solderability. Suitable for operating temperature extremes, ensuring stability in industrial environments.

Compliant with RoHS and UL standards for safety and environmental responsibility. Through hole mounting style for robust mechanical stability.

This Wurth Elektronik PCB header is widely used in industrial electronics, power generation, telecommunications, and manufacturing automation systems requiring reliable PCB connections under harsh operating conditions.
