Samtec T1M Series Right Angle Surface PCB Header 20 Contacts 2 mm Pitch 2 Row Shrouded T1M-10-GF-DH

Free Delivery in India | Lowest Global Shipping Charges

Samtec T1M Series Right Angle Surface PCB Header 20 Contacts 2 mm Pitch 2 Row Shrouded T1M-10-GF-DH

Name: Samtec T1M Series Right Angle Surface PCB Header 20 Contacts 2 mm Pitch 2 Row Shrouded T1M-10-GF-DH
Brand: Samtec
SKU: 402580
Price: 4.27 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Samtec
Orientation	Right Angle
Current	3.3A
Model	T1M-10-GF-DH
Mount Type	Surface
Housing Material	Natural LCP
Contact Material	Phosphor Bronze
Series	T1M
Termination Type	Solder
Maximum Operating Temperature	85°C
Minimum Operating Temperature	-10°C
Number of Rows	2
Pitch	2mm
Contact Plating	Silver, Tin
Number of Contacts	20
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
Row Pitch	1mm

Key Features

The connector supports a current rating of 3.3 A for reliable electrical performance.
It has a right angle orientation designed for surface mounting on PCBs.
Contact plating includes silver and tin over phosphor bronze for durability and conductivity.
Operates within a temperature range from -10°C to 85°C for versatile industrial use.
The connector is rated for up to 250 V voltage, suitable for low voltage electronic components.
The male pin termination type ensures secure solder connections on the board.
The product is shrouded, providing protection and polarization for the mating connector.

Product Description

Samtec T1M-10-GF-DH is a high-quality right angle surface mount PCB header designed for electronic and electrical applications. Featuring 20 male contacts arranged in 2 rows with a precise 2 mm pitch, this shrouded connector ensures robust wire-to-board connections in industrial settings.

Constructed with a natural liquid crystal polymer (LCP) housing, this header offers excellent mechanical stability and temperature resistance from -10°C up to 85°C. Contact materials include phosphor bronze plated with silver and tin, providing high conductivity and corrosion resistance. Rated for 3.3 A current and 250 V voltage, it is suitable for low power electronic assemblies demanding reliable interconnects.

The right angle orientation facilitates PCB layout flexibility, and the surface mount technology ensures secure solder termination with male pins. The shrouded design adds safety by preventing accidental contact and ensuring correct mating.

This connector is ideal for industrial electronics, manufacturing equipment, and any application where dependable board-to-wire connection is critical. It complies with necessary standards though does not carry specific certifications.

The connector supports a current rating of 3.3 A for reliable electrical performance. It has a right angle orientation designed for surface mounting on PCBs. Contact plating includes silver and tin over phosphor bronze for durability and conductivity.

Operates within a temperature range from -10°C to 85°C for versatile industrial use. The connector is rated for up to 250 V voltage, suitable for low voltage electronic components. The male pin termination type ensures secure solder connections on the board.

The product is shrouded, providing protection and polarization for the mating connector.
