Molex 206832 Series Vertical Through Hole PCB Header, 8 Contact, 3 mm Pitch, 2 Row, Shrouded 206832-0202

Free Delivery in India | Lowest Global Shipping Charges

Molex 206832 Series Vertical Through Hole PCB Header, 8 Contact, 3 mm Pitch, 2 Row, Shrouded 206832-0202

Name: Molex 206832 Series Vertical Through Hole PCB Header, 8 Contact, 3 mm Pitch, 2 Row, Shrouded 206832-0202
Brand: Molex
SKU: 401648
Price: 1086.37 USD
Availability: InStock



Category PCB Header Brand Molex Condition New

Specifications

Country of Origin	China
Brand	Molex
Orientation	Vertical
Current	12
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	High Copper Alloy
Series	206832
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	2
Pitch	3mm
Standards/Approvals	CHINA RoHS, EU RoHS
Contact Plating	Gold
Number of Contacts	8
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Micro Fit Connector System
Tail Pin Length	3.18mm

Key Features

Features a shrouded design to prevent accidental misalignment.
Supports a current rating of 12 amperes for robust electrical performance.
Operates safely at voltages up to 600 Vrms.
Constructed with a liquid crystal polymer housing for durability.
Contacts made from high copper alloy plated with gold for excellent conductivity.
Vertical orientation with through hole mount simplifies PCB installation.
Operates in temperatures ranging from -40°C to 105°C, suitable for harsh environments.
Dual row, 2 circuit configuration optimizes compact circuit designs.

Product Description

Molex 206832-0202 vertical through hole PCB header is designed for secure and reliable electrical connections in demanding industrial and electronic applications. This PCB header features an 8-contact, dual row design with a 3 mm pitch and a shrouded housing to enhance protection against damage or misalignment during installation. The Micro Fit connector system ensures compatibility with a wide range of equipment.

The connector's high copper alloy contacts with gold plating provide superior conductivity and corrosion resistance, while the liquid crystal polymer housing offers excellent mechanical strength and stability.

Rated for 12 amperes current and 600 Vrms voltage, the header supports robust power distribution within various automation and control systems. Its vertical orientation and through hole mount make it straightforward to install on printed circuit boards, optimizing assembly efficiency.

The header maintains performance across a wide temperature range from -40°C to +105°C, making it suitable for use in harsh industrial, mechanical control, and electronics environments. The dual row arrangement allows support for a maximum of 2 circuits, ideal for space-constrained designs requiring compact connectivity.

Shrouded housing enhances contact protection and connection stability. High current rating supports power demanding electronic tasks. Gold-plated high copper alloy contacts optimize electrical conductivity and longevity.

Durable liquid crystal polymer housing ensures mechanical robustness. Easy vertical through hole mounting compatible with PCB assembly processes. Wide operating temperature range suits industrial and mechanical control applications.

Dual rows enable dual circuit connectivity in compact layouts.

This PCB header is widely used in power distribution for automation systems, wire-to-board electronic connections, and mechanical control systems requiring reliable electrical interfaces. It is compliant with China RoHS and EU RoHS standards, ensuring environmental and safety adherence.
