Samtec TFM Series Straight Through Hole PCB Header, 14 Contacts, 1.27 mm Pitch, 2 Row, Shrouded, 3.2A TFM-107-02-L-D-DS

Free Delivery in India | Lowest Global Shipping Charges

Samtec TFM Series Straight Through Hole PCB Header, 14 Contacts, 1.27 mm Pitch, 2 Row, Shrouded, 3.2A TFM-107-02-L-D-DS

Name: Samtec TFM Series Straight Through Hole PCB Header, 14 Contacts, 1.27 mm Pitch, 2 Row, Shrouded, 3.2A TFM-107-02-L-D-DS
Brand: Samtec
SKU: 401412
Price: 8.97 USD
Availability: InStock



Category PCB Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	Samtec
Orientation	Straight
Current	3.2A
Model	TFM-107-02-L-D-DS
Mount Type	Through Hole
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TFM
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	1.27mm
Contact Plating	Gold
Number of Contacts	14
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Board-to-Board

Key Features

Comprises 14 male contacts arranged in 2 rows for compact board-to-board connections.
Pitch of 1.27 mm ensures high-density mounting capabilities.
Contact material is phosphor bronze with gold plating for reliable conductivity.
Black liquid crystal polymer housing provides excellent insulation and durability.
Supports a current rating of 3.2A per contact and voltage rating of 250 VAC.
Designed with shrouded straight orientation for secure mating connectors.
Termination type is solder compatible for through-hole mounting.
Operating temperature range from -55°C to +125°C suitable for industrial applications.

Product Description

Samtec TFM-107-02-L-D-DS is a high-reliability PCB header from the TFM series, designed for board-to-board connections in electronic assemblies. This straight through hole header features 14 male contacts arranged in 2 rows with a 1.27 mm pitch, allowing for dense and reliable interconnections on printed circuit boards.

The connector housing is made from black liquid crystal polymer, offering excellent insulation properties and mechanical strength. Contacts are fabricated from phosphor bronze and plated with gold to ensure superior electrical conductivity and corrosion resistance, making it suitable for demanding industrial and commercial applications.

This PCB header supports a current rating of 3.2A per contact and a voltage rating of 250 VAC, with an operating temperature range from -55°C to +125°C. Its shrouded design provides protection and ensures proper mating with complementary connectors, enhancing connection security and durability.

Ideal for use in electronic component manufacturing, power connectors, automation equipment, and telecommunications hardware, this header exemplifies quality and performance for circuit board connectivity.

Comprises 14 male contacts arranged in 2 rows for compact board-to-board connections. Pitch of 1.27 mm ensures high-density mounting capabilities. Contact material is phosphor bronze with gold plating for reliable conductivity.

Black liquid crystal polymer housing provides excellent insulation and durability. Supports a current rating of 3.2A per contact and voltage rating of 250 VAC. Designed with shrouded straight orientation for secure mating connectors.

Termination type is solder compatible for through-hole mounting. Operating temperature range from -55°C to +125°C suitable for industrial applications. Connector system is board-to-board type optimized for printed circuit board assemblies.

Robust construction with high-reliability Tiger Eye terminals ensuring long service life. Explore EnvMart's comprehensive range of PCB Headers and electronic components to find high-quality parts suited for your industrial and manufacturing needs.
