Panasonic PCB Power Relay 12V DC Coil 16A Switching Current SPST ADW1112HLW
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.8mm |
| Length | 24mm |
| Model | ADW1112HLW |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ADW1 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Switching Current | 16A |
| Terminal type | PCB Pin |
| Contact Resistance | 100mΩ |
| Standards/Approvals | UL, VDE, CSA, cUL, cULus, PTI 325V, TV-8 |
| Coil Resistance | 720Ω |
| Coil Voltage | 12V dc |
| Switching AC Voltage | 277V ac |
| Coil Power | 200mW |
Key Features
- Rated for coil voltage of 12V DC ensuring low power consumption.
- Single Pole Single Throw (SPST) contact configuration for standard switching operations.
- Supports switching currents up to 16A at a maximum AC voltage of 277V.
- Operates reliably in temperatures from -40°C to 70°C.
- Compact dimensions of 24mm length, 10mm width, and 15.8mm height.
- Low coil power dissipation of 200mW enhances energy efficiency.
- Contact material is silver alloy providing low resistance and durability.
- Coil resistance of 720Ω for stable coil performance.
Product Description
Panasonic ADW1112HLW PCB Power Relay is a compact and robust Power Relay featuring a 12V DC coil and 16A switching current rated for industrial and appliance use. Designed for high reliability, it is capable of operating under stressful conditions with a compact size of 24mm in length, 10mm width, and 15.8mm height. The relay supports a single pole single throw (SPST) contact configuration and switching AC voltage up to 277V.
The relay operates efficiently with a coil power consumption of 200mW and a coil resistance of 720 ohms, making it suitable for various automation and control systems. Its silver alloy contact material ensures low contact resistance at 100mΩ and superior durability. The relay withstands operating temperatures ranging from -40°C to 70°C, making it appropriate for use in appliances, lighting, smart meters, power supplies, refrigerators, and washing machines.
Highly reliable and compact, this Panasonic relay assures robust performance in energy, lighting, industrial, and white goods applications. The product originates from Thailand and complies with standards including UL, VDE, CSA, cUL, cULus, PTI 325V, and TV-8.
Rated for 12V DC coil voltage providing efficient control. SPST contact configuration suitable for various switching needs. Supports switching currents up to 16A and AC voltage up to 277V. Compact dimensions enable space-saving PCB integration.
Low coil power consumption enhances overall energy efficiency. Silver alloy contacts ensure long service life and low resistance. Wide operating temperature range from -40°C to 70°C for diverse environments. Complies with multiple international safety certifications.
Designed for industrial, appliance, lighting, and automation applications. Manufactured in Thailand under Panasonic quality standards. Explore more Panasonic relays and electronic components across EnvMart for industrial, manufacturing, and automation solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a coil voltage of 12V DC, ensuring low power consumption during operation.
It supports a maximum switching current of 16A, making it suitable for various applications.
This model features a Single Pole Single Throw (SPST) contact configuration for standard switching operations.
The relay has compact dimensions of 24mm in length, 10mm in width, and 15.8mm in height, allowing for space-saving PCB integration.
It operates reliably in temperatures ranging from -40°C to 70°C, making it suitable for diverse environments.
The contact material is silver alloy, which provides low resistance and enhances durability.
The relay has a coil power consumption of 200mW, contributing to its energy efficiency.
The contact resistance is 100mΩ, ensuring low resistance during operation.
It complies with several standards including UL, VDE, CSA, cUL, cULus, PTI 325V, and TV-8, ensuring safety and reliability.
The coil resistance is 720Ω, which contributes to stable coil performance.
It is designed for use in industrial, appliance, lighting, and automation applications, making it versatile for various control systems.
This model can switch AC voltage up to 277V, making it suitable for high-voltage applications.
