Panasonic PCB Power Relay 12V DC Coil 10A Switching Current SPDT ALQ112
Specifications
| Country of Origin | Thailand |
|---|---|
| Brand | Panasonic |
| Height | 15.6mm |
| Length | 20mm |
| Model | ALQ112 |
| Width | 10mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | ALQ |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Ambient Temperature | - 40°C to +85°C |
| Contact Resistance | 100mΩ |
| Standards/Approvals | CQC, cUL, VDE, UL, cULus, CSA |
| Coil Resistance | 360Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 30V dc |
| Switching AC Voltage | 250V |
| Coil Power | 400mW |
| High surge voltage | 8000 V |
| High breakdown voltage | 4000 V |
Key Features
- Compact design suitable for PCB mounting and various applications.
- Coil resistance is 360 ohms ensuring reliable coil operation.
- Rated switching power up to 500 VA supporting high load switching.
- Wide operating temperature range from -40°C to 85°C for robust performance.
- High surge voltage rating of 8000 V and breakdown voltage of 4000 V.
- Contact parts made from silver alloy offering low contact resistance of 100 mΩ.
- Coil power consumption is low at 400 mW for energy efficiency.
- Mounting type is PCB with terminal type as PCB pins for easy integration.
Product Description
Panasonic ALQ112 PCB Power Relay is a compact and highly reliable power relay designed for PCB mounting applications. It operates with a 12V DC coil voltage and supports a switching current of 10A with an SPDT contact configuration, making it ideal for switching loads up to 500 VA.
The relay includes features such as low coil power consumption of 400 mW and a coil resistance of 360 ohms, which enhances energy efficiency and performance stability. Designed for harsh industrial and consumer environments, it performs reliably in a wide ambient temperature range from -40°C to 85°C.
The dimensions of the relay are 20 mm in length, 15.6 mm in height, and 10 mm in width, providing a space-saving solution for high-density PCB assemblies. The contact material is silver alloy, offering low contact resistance of 100 mΩ and ensuring consistent switching quality under high surge and breakdown voltages of 8000 V and 4000 V respectively.
This Panasonic ALQ112 is compliant with multiple international standards including CQC, cUL, VDE, UL, cULus, and CSA, further validating its suitability for industrial, automation, home appliances, and HVAC control systems.
Compact design suits appliances, industrial equipment, power supplies, motors, and robotics. High insulation resistance and surge capacity ensure long-term durability. PCB mounting and pin terminals facilitate easy installation and replacement.
Reliable switching of both AC and DC loads with 250 V AC and 30 V DC switching voltages. Extensive temperature rating supports operation in diverse environmental conditions.
This power relay is an essential component for industrial, laboratory, HVAC, and manufacturing applications requiring stable, efficient electrical load switching. Browse EnvMart’s Electronics & Electricals category for related relays and contactors to complement your electrical design needs.
Explore more products in our Power Relays category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ALQ112 power relay operates with a coil voltage of 12V DC.
This model can handle a maximum switching current of 10A.
The dimensions of the relay are 20 mm in length, 15.6 mm in height, and 10 mm in width.
The ALQ112 features a Single Pole Double Throw (SPDT) contact configuration.
The coil resistance of the ALQ112 is 360 ohms.
It supports a rated switching power of up to 500 VA.
The relay operates reliably in a wide temperature range from -40°C to 85°C.
The contact parts of this relay are made from silver alloy, providing low contact resistance.
This model has a low coil power consumption of 400 mW.
The ALQ112 has a high surge voltage rating of 8000 V and a breakdown voltage of 4000 V.
The relay is designed for PCB mounting with PCB pin terminals for easy integration.
This power relay is compliant with standards including CQC, cUL, VDE, UL, cULus, and CSA.
