i-Autoc KSI Series Solid State Relay Panel Mount 25A Load 280V AC Load 280V AC Control KSI240A25-L

i-Autoc KSI240A25-L solid state relay is a reliable industrial-grade relay designed for single-phase AC load switching. Featuring a panel mount form factor and screw terminal connections, it delivers a maximum load current of 25A at 280 V AC. The relay supports a load voltage range from 48 V AC to 280 V AC and control voltage from 90 V AC to 280 V AC, making it versatile for diverse automation environments.

Constructed with an IP20-rated touch-safe cover, this relay ensures user safety while providing robust performance. Its zero cross switching function minimizes electrical noise and stress on connected loads. The output employs SCR and triac technology for efficient and precise switching of resistive, inductive, and capacitive loads.

The compact dimensions of 58.6 mm length, 45.7 mm width, and 27 mm height allow for easy integration into control panels. Operating within temperature extremes from -30°C to 80°C, this relay is suitable for environments such as HVAC systems, plastics manufacturing machinery, incubation machines, oiling machines, elevators, lighting installations, and fountain controllers.

Built-in dielectric strength of 400 VAC RMS and integrated RC snubber, MOV, and TVS protection components enhance durability and longevity under electrical transients. The product complies with RoHS, CE, and CCC standards and is manufactured in China.

Designed for secure panel mounting with screw terminals. Maximum load current of 25 amperes at 280 volts AC handling capacity. Zero cross switching minimizes electrical interference. IP20 rated touch-safe housing for protection.

Supports resistive, inductive, and capacitive load types. SCR and triac output configuration. Compact dimensions optimize installation space. Operates from -30°C to +80°C ambient temperatures. Dielectric strength of 400 VAC RMS for electrical safety.

Includes internal RS/MOV and TVS protection.

This solid state relay from i-Autoc is suitable for industrial, automation, HVAC, manufacturing, and laboratory control applications requiring efficient and reliable AC load switching. Explore more Solid State Relays and related control equipment in the Electronics & Electricals category on EnvMart.
