i-Autoc Solid State Relay DIN Rail Mount 24V DC Coil 25mA 20A Switching Current KSV240D20-LM
Specifications
| Country of Origin | China |
|---|---|
| Brand | i-Autoc |
| Height | 112.5mm |
| Length | 100mm |
| Model | KSV240D20-LM |
| Width | 30.5mm |
| Mount Type | DIN Rail |
| Series | KSV |
| Maximum Operating Temperature | 80°C |
| Minimum Operating Temperature | -30°C |
| Switching Current | 20A |
| Terminal type | PCB Terminal |
| Standards/Approvals | RoHS |
| Coil Voltage | 24V dc |
| Coil Current | 25mA |
| Switching DC Voltage | 24V dc |
Key Features
- Designed for mounting on 35 mm DIN Rail or panel screw mounting.
- Integrated heatsink for improved thermal management.
- SCR output with zero crossing switching feature.
- LED indication for operational status.
- Built-in RC snubber circuit for enhanced reliability.
- Wide operating temperature range from -30°C to 80°C.
- Dielectric strength of 4000 V AC RMS for electrical safety.
- Suitable for industrial automation and control applications.
Product Description
The i-Autoc KSV240D20-LM is a high-quality single-phase Solid State Relay (SSR) designed for industrial and commercial use, featuring a robust 24V DC coil and a switching current rating of 20A. This relay is integrated with a heatsink and is suitable for mounting on a 35 mm DIN Rail or by panel screws, providing flexible installation options for control panels and electrical enclosures.
Equipped with SCR output technology, the relay supports zero crossing switching ensuring reduced electrical noise and extended device life. The built-in RC snubber circuit improves transient voltage protection, while the LED indicator facilitates easy monitoring of the relay's operational state. This SSR operates reliably within a temperature range of -30°C to 80°C, making it suitable for diverse industrial environments.
The relay offers a dielectric strength of 4000 V AC RMS, providing robust insulation and safety for sensitive electrical components. Its compact form factor, measuring 100 mm in length, 30.5 mm in width, and 112.5 mm in height, allows for space-efficient panel integration.
Typical applications include industrial automation systems, electromechanical interface relays, and various control circuits requiring noise-free switching and high reliability. The product complies with RoHS standards, ensuring environmental safety.
Designed for mounting on 35 mm DIN Rail or panel screw mounting. Integrated heatsink for improved thermal management. SCR output with zero crossing switching feature. LED indication for operational status. Built-in RC snubber circuit for enhanced reliability.
Wide operating temperature range from -30°C to 80°C. Dielectric strength of 4000 V AC RMS for electrical safety. Compact dimensions: Length 100mm, Width 30.5mm, Height 112.5mm. Suitable for industrial automation and control applications.
Explore more Solid State Relays and industrial control solutions available at EnvMart for your automation and electrical system needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switching current rating of this solid state relay is 20A.
The coil voltage for the KSV240D20-LM model is 24V DC.
This relay measures 100 mm in length, 30.5 mm in width, and 112.5 mm in height.
The operating temperature range for this unit is from -30°C to 80°C.
This solid state relay can be mounted on a 35 mm DIN Rail or by panel screws.
Yes, it features a built-in RC snubber circuit for enhanced reliability and a dielectric strength of 4000 V AC RMS for electrical safety.
This relay uses SCR output technology with zero crossing switching, which helps reduce electrical noise.
The relay is equipped with PCB terminals for easy connection.
This product complies with RoHS standards, ensuring environmental safety.
It is suitable for industrial automation systems, electromechanical interface relays, and control circuits requiring noise-free switching.
The coil current for this solid state relay is 25mA.
This relay includes an LED indicator that facilitates easy monitoring of its operational status.
