i-Autoc KSJ Series Solid State Relay Panel Mount 80A Load 100V dc Load 32V dc Control KSJ100D80-L(068)

i-Autoc KSJ100D80-L(068) Solid State Relay is a DC output, panel-mounted device designed for controlled switching of DC loads. This 80A load relay operates at a maximum load voltage of 100V dc with a control input voltage ranging from 4V to 32V dc. Featuring zero cross switching, this relay ensures smooth and safe load switching by activating near zero voltage crossing points, reducing electrical noise and stress on connected components.

The relay is constructed with a durable IP20 rated touch safe cover and uses screw terminals for secure electrical connections. It offers opto-isolation between input and output with a dielectric strength of 2500 VAC rms, resulting in enhanced safety and reliability.

Compact in size with dimensions measuring 58.6mm in length, 45.7mm in width, and 27mm in height, the KSJ100D80-L(068) series is well suited for panel mounting in industrial, automation, and manufacturing control systems. Its operating temperature range of -30°C to +80°C enables it to function reliably under a broad range of environmental conditions.

This relay is ideal for applications involving DC heating control, DC power switching, DC motor control, solar energy systems, valves, and various industrial automation processes requiring robust and precise DC switching capability.

The low off state leakage current of 0.1mA minimizes power losses and heat generation, contributing to system efficiency. The product is RoHS compliant, and certified under CCC and CE standards, assuring quality and environmental safety standards adherence.

Supports a maximum load current of 80A. Operates with load voltage up to 100V dc. Control voltage range from 4V to 32V dc. Panel mount type relay with screw terminal connectivity. Zero cross switching function for safe and reliable operation.

IP20 rated touch safe housing. Operating temperature range from -30°C to 80°C. Compact dimensions of 58.6mm (L) x 45.7mm (W) x 27mm (H). Dielectric strength ≥2500VACrms with opto-isolation feature. Low off state leakage current (0.1mA) improves efficiency.

Applications including DC heating, solar energy, and motor control. Explore a wide range of Solid State Relays and related components in the Electronics & Electricals category at EnvMart for industrial and laboratory use.
