JST PHD Series Straight Through Hole Shrouded PCB Header 18 Contacts 2 mm Pitch 2 Row B18B-PHDSS (LF)(SN)
Specifications
| Country of Origin | Malaysia |
|---|---|
| Voltage | 250V |
| Brand | JST |
| Orientation | Straight |
| Current | 3A |
| Model | B18B-PHDSS (LF)(SN) |
| Mount Type | Through Hole |
| Housing Material | Polyamide |
| Contact Material | Copper Alloy |
| Series | PHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 2 |
| Pitch | 2mm |
| Contact Plating | Tin |
| Number of Contacts | 18 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Mating Pin Length | 2.9mm |
Key Features
- Compact 2.0 mm pitch ensures high density connections.
- Shrouded housing prevents incorrect mating and flux intrusion.
- Constructed with polyamide housing for durability.
- Designed for wire-to-board connections using through hole mounting.
- Rated for 3A current and 250V voltage operation.
- Contact plating of tin enhances corrosion resistance.
- Male copper alloy contacts with 2.9 mm mating pin length.
- Operates reliably between -25°C and 85°C temperatures.
Product Description
JST B18B-PHDSS (LF)(SN) PCB Header is a shrouded, straight through hole connector featuring 18 male contacts arranged in 2 rows with a 2 mm pitch. The connector utilizes polyamide housing to ensure durability and resistance against environmental factors. Its design prevents incorrect mating and inhibits flux and contaminant intrusion, ideal for maintaining signal integrity in industrial and commercial electronic assemblies.
This PHD series connector is rated for 3 Ampere current and a voltage of up to 250 Volts, supporting reliable performance in demanding power and signal transmission applications. Tin-plated copper alloy contacts offer excellent conductivity and resistance to corrosion. The mating pin extends 2.9 mm to ensure secure and stable connectivity.
Operating temperature range extends from -25°C to 85°C, making this component suitable for a variety of industrial environments. The wire-to-board mount type through hole installation facilitates robust mechanical and electrical connections on printed circuit boards.
Its compact low profile and double row contact arrangement enable efficient space utilization on PCBs, addressing high-density interconnection needs in consumer electronics, communication equipment, instrumentation, and control systems.
Compact 2 mm pitch design. Durable polyamide housing material. Shrouded construction for secure mating. Through hole mount for reliable mechanical fixation. Male copper alloy contacts with tin plating for longevity. 3A current and 250V voltage ratings.
Wide operating temperature range from -25°C to 85°C. Double row layout for improved contact density. Manufactured in Malaysia adhering to quality standards. This JST PCB Header is suited to electronics manufacturing, automation, instrumentation, and communications industries requiring dependable, high-quality board interconnections.
Explore more high-performance PCB connectors and components in the Electronics & Electricals category at EnvMart for your industrial and commercial projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model is rated for a current of 3 Amperes and a voltage of up to 250 Volts, making it suitable for various power and signal transmission applications.
The connector features a compact pitch size of 2 mm, allowing for high-density connections on printed circuit boards.
It operates reliably within a temperature range of -25°C to 85°C, making it suitable for diverse industrial environments.
The housing is made of polyamide, while the contacts are constructed from copper alloy with tin plating for enhanced conductivity and corrosion resistance.
This model features a total of 18 male contacts arranged in 2 rows, facilitating efficient connections.
It utilizes through hole mounting, which provides robust mechanical and electrical connections on printed circuit boards.
The mating pin length is 2.9 mm, ensuring secure and stable connectivity when mated with compatible connectors.
The connector is designed with a straight orientation, which is standard for many PCB applications.
This model is shrouded, which helps prevent incorrect mating and protects against flux intrusion.
It is manufactured in Malaysia, adhering to quality standards for electronic components.
The termination type for this model is solder, which is commonly used for reliable connections on PCBs.
This connector is suitable for use in electronics manufacturing, automation, instrumentation, and communications industries.
