TDK Chassis Mount EMC Filter, 1 Phase, 2 A, 250V AC/DC, 50/60 Hz, Capacitance 2pF, Inductance 2mH, Model B84112G0000B020

TDK model B84112G0000B020 is a 1-phase chassis mount EMC filter designed for use in industrial and commercial electronic equipment. It supports a maximum current rating of 2 amperes and maximum voltage of 250 volts AC/DC, working effectively at both 50 Hz and 60 Hz frequencies. This filter incorporates two line filters packed in a compact metal casing that simplifies installation and offers durability.

The capacitance value of this EMC filter is 2 picoFarads, and its inductance is 2 milliHenrys, designed to efficiently suppress electromagnetic interference and ensure stable operation of sensitive electronics. Featuring a low leakage current of 369 microamperes, it is well suited for applications requiring stringent safety and minimal interference.

Operating temperature range spans from minus 25 degrees Celsius up to 100 degrees Celsius, enabling performance in various environmental conditions. Its chassis mount design and tab-type termination style facilitate easy and reliable mounting and wiring. Dimensionally, the product measures 72 mm in length, 46 mm in depth, and 26 mm in height, optimizing space usage within assemblies.

Typical applications include use in industrial electronics, switch-mode power supplies, telecom systems, data communication devices, DC powered equipment, and specific medical equipment models (B84112G0000M*). The product complies with UL1283 standards, assuring adherence to recognized safety requirements. Manufactured in China, this EMC filter delivers reliable suppression of noise and interference to enhance equipment performance and longevity.

This EMC filter features a compact metal case design for easy installation. Constructed with two line filters providing enhanced insertion loss performance. Capacitance is rated at 2 pF and inductance at 2 mH for effective noise suppression.

Leakage current is low at 369 μA, ensuring safety in diverse applications. The filter operates reliably between -25°C and 100°C ambient temperatures. Mounting is chassis type with tab termination style for secure electrical connections.

Dimensions measure 72 mm length, 46 mm depth, and 26 mm height for space-efficient mounting. Suitable for industrial electronics, switch-mode power supplies, telecom, data systems, DC applications, and medical equipment variants.

Complies with UL1283 safety standards, ensuring quality and reliability. Country of origin is China.

This TDK EMC Filter is ideal for engineers and technicians seeking reliable electromagnetic interference suppression solutions in industrial, telecommunications, data processing, manufacturing, and medical equipment contexts. Explore more filters and related products in the Electronics Components category of EnvMart for comprehensive power quality and EMC management.
