TDK Single Phase Chassis Mount EMC Filter 12A 250V AC/DC 50Hz 60Hz Tab Termination B84112G0000B112

Free Delivery in India | Lowest Global Shipping Charges

TDK Single Phase Chassis Mount EMC Filter 12A 250V AC/DC 50Hz 60Hz Tab Termination B84112G0000B112



Category EMC Filter Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	29mm
Length	84.7mm
Model	B84112G0000B112
Depth	52mm
Mount Type	Chassis Mount
Operating Frequency	50, 60Hz
Series	B84112G
Maximum Operating Temperature	100°C
Number Of Stages	1
Capacitance	2pF
Minimum Operating Temperature	-25°C
Maximum Current	12A
Number of Phases	1
Leakage Current	369μA
Maximum Voltage	250V ac/dc
Inductance	2mH
Standards/Approvals	UL 1283
Termination Style	Tab

Key Features

Compact chassis mount design with tab termination for easy installation.
Rated for maximum current of 12 amps and voltage of 250V AC/DC.
Operates effectively at frequencies of 50Hz and 60Hz.
Complies with UL 1283 standard for safety and performance.
Suitable for applications including switch-mode power supplies and telecom systems.
Constructed with 2 line filters and metal casing for durability.
Features low capacitance of 2 pF and leakage current of 369 μA.
Wide operating temperature range from -25°C to 100°C ensures performance in harsh environments.

Product Description

TDK offers the B84112G0000B112 chassis mount EMC filter designed for single phase systems requiring electromagnetic interference suppression. This compact unit features a robust metal casing and consists of two line filters providing enhanced insertion loss for industrial and commercial applications.

The filter has a rated maximum current of 12A and supports a voltage of 250V AC/DC, operating efficiently at frequencies of 50Hz and 60Hz. Its tab termination style facilitates straightforward installation on chassis mounts.

Capacitance is measured at 2 pF, and the inductance is 2 mH, with leakage current of 369 μA ensuring low noise emission. Designed to operate between -25°C and 100°C, it meets UL 1283 standards, reflecting its compliance with stringent safety and performance requirements.

This EMC filter is ideal for use in industrial electronics, switch-mode power supplies, telecom and data systems, DC-powered devices, and certain medical equipment variants. The metal construction ensures durability and protection against environmental factors.

Compact chassis mount with tab terminations. 12A maximum current at 250V AC/DC operation. Wide frequency compatibility at 50Hz and 60Hz. Low capacitance and leakage current provide high performance. Conforms to UL 1283 safety standard.

Suitable for diverse industrial and telecommunications applications. Constructed with durable metal case and two line filters. Operating temperature tolerance from -25°C to 100°C.

This product is manufactured in China and sold new. It is packaged ready for machine insertion to support production efficiency improvements. Opt for the TDK B84112G0000B112 for dependable EMC noise filtering in your electrical systems.
