TDK Chassis Mount EMC Filter 2 A 250 V AC/DC 50/60 Hz Tab 1 Phase B84112G0000B020

Free Delivery in India | Lowest Global Shipping Charges

TDK Chassis Mount EMC Filter 2 A 250 V AC/DC 50/60 Hz Tab 1 Phase B84112G0000B020



Category EMC Filter Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	26mm
Length	72mm
Model	B84112G0000B020
Depth	46mm
Mount Type	Chassis Mount
Operating Frequency	50, 60Hz
Series	B84112G
Maximum Operating Temperature	100°C
Number Of Stages	1
Capacitance	2pF
Minimum Operating Temperature	-25°C
Maximum Current	2A
Number of Phases	1
Leakage Current	369μA
Maximum Voltage	250V ac/dc
Inductance	2mH
Standards/Approvals	UL1283
Termination Style	Tab

Key Features

Compact and easy-to-install chassis mount design ensures convenient setup.
Capacitance of 2 pF and inductance of 2 mH for effective EMI filtering.
Rated for maximum operating temperature of 100°C and minimum of -25°C.
Features tab-style termination for secure electrical connections.
Leakage current is low at 369 μA, enhancing safety and efficiency.
Complies with UL1283 standard for EMI filters.
Ideal for industrial electronics, switch-mode power supplies, telecom, data systems, and medical equipment.
Single-phase filter with one stage in B84112G series.

Product Description

TDK B84112G0000B020 chassis mount EMC filter is engineered for single-phase electrical systems, capable of handling a maximum current of 2 A and operating voltage up to 250 V AC/DC at 50 or 60 Hz frequencies. This compact filter features a chassis mount type with tab termination for quick and reliable installation in a variety of industrial and electronics applications.

The filter incorporates a capacitance of 2 pF and inductance of 2 mH, providing effective electromagnetic interference suppression. Its operating temperature range from -25°C to 100°C ensures reliable performance under diverse environmental conditions. The leakage current value is 369 μA, ensuring minimal power loss and enhanced safety compliance.

Designed in accordance with UL1283 standards, this EMC filter is suitable for use in industrial electronics, switch-mode power supplies, telecom systems, data systems, and medical equipment (special versions applicable for medical use).

The B84112G series delivers an efficient one-stage filtering solution in a metallic case for durability and improved insertion loss. Its compact design allows it to be easily integrated into existing systems to enhance electromagnetic compatibility and reduce noise.

Compact chassis mount type improves device integration. Rated voltage of 250 V AC/DC supports multiple systems. 2 A current rating suited for low to moderate power filtering needs. Tab termination style ensures secure connections.

One-phase, one-stage filter enhances EMI suppression. Wide operating temperature range supports harsh environments. Meets UL1283 standard, assuring quality and safety. Applications include industrial electronics, telecom, data systems, switch-mode power supplies, and medical equipment.
