Wurth Elektronik WCAP-FTX2 Polypropylene Film Capacitor X2 Safety Class 6.8μF 275V DC 275V AC ±10% Through Hole FTX2

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WCAP-FTX2 Polypropylene Film Capacitor X2 Safety Class 6.8μF 275V DC 275V AC ±10% Through Hole FTX2

Name: Wurth Elektronik WCAP-FTX2 Polypropylene Film Capacitor X2 Safety Class 6.8μF 275V DC 275V AC ±10% Through Hole FTX2
Brand: Wurth Elektronik
SKU: 383135
Price: 8.3 USD
Availability: InStock



Category Film Capacitor Brand Wurth Elektronik Condition New

Specifications

Country of Origin	India
Brand	Wurth Elektronik
Operating Temperature	-40 °C to +105°C
Height	35.5mm
Length	41.5mm
Model	FTX2
Width	22.5mm
Mount Type	Through Hole
Series	WCAP-FTX2
Maximum Operating Temperature	105°C
Tolerance	±10 %
Capacitance	6.8μF
Minimum Operating Temperature	-40°C
Terminal type	Solder
Dissipation Factor	0.7%
Lead Length	4mm
Standards/Approvals	VDE, ENEC, cULus, CQC
Package/Case	500
Rated AC Voltage	275V ac
Rated DC Voltage	275V dc
Lead Pitch	37.5mm
Lead Diameter	1mm
Applications include	Safety applications, Filter and Power Supplies
Suppression Class	X2

Key Features

Constructed using metallized polypropylene film with self-healing properties.
Through-hole mounting with a solder terminal and 37.5mm lead pitch for PCB installation.
Rated operating temperature range from -40°C to +105°C.
Compliant with VDE, ENEC, cULus, and CQC safety approvals.
Encapsulated in UL94V-0 rated self-extinguishing material for safety.
Designed for EMI filtering, interference suppression, and power supply filters.
Lead length is 4mm with a diameter of 1mm for robust connections.
Physical dimensions are 41.5mm length, 35.5mm height, and 22.5mm width.

Product Description

Wurth Elektronik FTX2 Polypropylene Film Capacitors, Model FTX2, are designed as safety class X2 capacitors with capacitance of 6.8μF and rated voltage of 275V DC and 275V AC. These capacitors utilize metallized polypropylene film technology, offering superior electrical performance with self-healing properties.

They are intended for use in safety applications, EMI filtering, interference suppression coils, and power supply filters. The capacitors are through-hole mounted with a lead pitch of 37.5mm and a solder terminal type, providing secure mechanical and electrical connections on PCB assemblies.

The operating temperature range from -40°C to +105°C allows their use in demanding industrial and electronic environments. The capacitors meet strict safety and quality approvals including VDE, ENEC, cULus, and CQC certification, ensuring compliance with global standards.

Physically, the capacitors have a length of 41.5mm, height of 35.5mm, width of 22.5mm, lead diameter of 1mm, and 4mm lead length, encapsulated in a UL94V-0 rated self-extinguishing housing enhancing safety reliability.

The low dissipation factor of 0.7% minimizes energy losses, contributing to efficient circuit operation. Available in package case 500, these capacitors are suitable for volume manufacturing and assembly line deployment.

Constructed using metallized polypropylene film with self-healing properties. Rated for -40°C to +105°C operation ensuring broad environmental resilience. Compliant with VDE, ENEC, cULus, and CQC safety approvals. Through-hole mount type with 37.5mm lead pitch and solder terminals.

Designed for EMI filters, safety circuits, and power supplies. Compact dimensions allow easy PCB integration. Low dissipation factor of 0.7% for energy efficiency. Encapsulated with UL94V-0 self-extinguishing plastic for fire safety.

Lead length 4mm and diameter 1mm ensure mechanical strength.

These capacitors are ideal for industrial, electronic manufacturing, power supply design, and safety application use cases. Explore more Wurth Elektronik components and Film Capacitors at EnvMart for reliable electronic components.
