Wurth Elektronik WR-PHD Series Right Angle Through Hole Pin Header 12 Contacts 2.54 mm Pitch 1 Row Unshrouded 61301211021

Wurth Elektronik model 61301211021 WR-PHD Series is a right angle through hole pin header connector designed with precision for electronic and industrial applications requiring reliable board-to-board connections.

This connector features 12 male contacts arranged in a single row with a 2.54 mm pitch, optimizing space and electrical performance on printed circuit boards.

The housing is made of black polyamide material rated UL94-V0 for flame retardance, ensuring safety and durability during operation. The contacts are crafted from copper alloy with gold plating, enhancing corrosion resistance and electrical conductivity.

With a current specification of 3 amperes and voltage rating up to 250 volts, this PCB Header connector is ideal for various assemblies requiring moderate power transfer. Engineered for right-angle orientation, it supports through hole mounting, promoting mechanical stability on the PCB.

Operating temperature range from -40°C to 105°C allows the connector to perform reliably in diverse environmental conditions including industrial, manufacturing, and electronic testing environments.

The connector tail pins extend 3 mm to ensure ease of soldering process, and mating pin length is 6 mm to accommodate proper interface connections with complementary components. This product does not hold specific industry certifications but meets general construction and electrical standards typical within the connector industry.

Wurth Elektronik WR-PHD Series connectors offer dependable performance in electronic manufacturing, embedded system development, industrial automation, and laboratory instrumentation. Their robust design supports improved production efficiency and consistent electrical performance.

Features a single row of unshrouded male pins suitable for board-to-board connections. Constructed with a polyamide housing for durable insulation. Gold-plated copper alloy contacts ensure reliable conductivity. Supports a voltage rating of up to 250 V and current rating of 3 A.

Designed for right angle orientation with through hole mount type for secure PCB attachment. Operates reliably in temperatures ranging from -40°C to 105°C. Tail pin length is 3 mm with a mating pin length of 6 mm. Complies with no formal standards or approvals, suitable for general electronic applications.

Designed for solder termination and equipped with a UL94-V0 black PBT insulator. Manufactured origin: Taiwan, Province Of China. Explore more connectors and electronic components from Wurth Elektronik on EnvMart for high-quality, reliable PCB solutions.
