Wurth Elektronik WR-BHD Series Straight Cable PCB Header, 24 Contacts, 2.54 mm Pitch, 2 Row, Shrouded 61202421621
Specifications
| Country of Origin | Taiwan |
|---|---|
| Voltage | 250V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 3A |
| Mount Type | Cable |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Copper Alloy |
| Series | WR-BHD |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
Key Features
- Features a shrouded design enhancing connector safety.
- Constructed with a Polybutylene Terephthalate housing for durability.
- Gold-plated copper alloy contacts ensure reliable electrical connection.
- Rated for 3A current and 250V voltage operation.
- Operates within a temperature range of -40°C to 105°C for versatile applications.
- Designed for wire-to-board connections with solder termination.
- Male contact gender suitable for various PCB interfaces.
- Manufactured in Taiwan, Province Of China, assuring quality compliance.
Product Description
Wurth Elektronik 61202421621 WR-BHD Series Straight Cable PCB Header is a precision connector designed for efficient wire-to-board applications. Featuring a 2.54 mm pitch with 24 male contacts arranged in 2 rows, this shrouded header ensures secure and reliable connections for electronic assemblies.
The housing is made of robust Polybutylene Terephthalate material with UL94-V0 flame retardant rating, guaranteeing durability and safety during operation. The contacts are fabricated from a copper alloy and plated with gold, providing excellent conductivity and resistance to corrosion.
This PCB header supports a maximum current of 3A and voltage rating of 250V, making it suitable for various industrial, electronic, and power connector applications. It performs reliably across a wide temperature range from -40°C to 105°C, allowing deployment in harsh environments.
The straight orientation and cable mount type facilitate easy integration into PCB designs, while solder termination type ensures solid mechanical and electrical connection. This product is manufactured in Taiwan, Province Of China, adhering to high-quality manufacturing standards.
Features a shrouded connector design for improved safety and protection. Durable Polybutylene Terephthalate housing ensures long service life. Gold-plated copper alloy contacts for enhanced conductivity and corrosion resistance.
Supports 3A rated current and 250V maximum voltage operation. Wide operating temperature range from -40°C to 105°C for versatile usage. Wire-to-board connector system suitable for cable mounting applications. Male contact gender with solder termination for robust assembly.
Manufactured complying with high-quality standards in Taiwan, Province Of China.
This Wurth Elektronik WR-BHD series PCB Header is ideal for use in electronics manufacturing, industrial automation, telecom equipment, and other power connector applications requiring reliable, compact cable-to-board connections.
Explore EnvMart's extensive range of Wurth Elektronik products and PCB connectors for quality assurance and technical support.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB header supports a maximum current of 3A and a voltage rating of 250V, making it suitable for various applications.
The header features a pitch of 2.54 mm and includes 24 male contacts arranged in 2 rows.
The housing is made of Polybutylene Terephthalate, and the contacts are constructed from a copper alloy with gold plating for enhanced conductivity.
It operates reliably within a temperature range of -40°C to 105°C, suitable for deployment in harsh environments.
This model features a solder termination type, ensuring a solid mechanical and electrical connection.
Yes, it is specifically designed as a wire-to-board connector system, facilitating easy integration into PCB designs.
The header has a straight orientation, which aids in its installation and connection to PCBs.
This PCB header is manufactured in Taiwan, Province Of China, ensuring compliance with high-quality standards.
The contact gender for this model is male, suitable for various PCB interfaces.
Yes, it features a shrouded design that enhances connector safety and protection during operation.
This model is ideal for electronics manufacturing, industrial automation, telecom equipment, and other power connector applications.
The header consists of 2 rows of contacts, providing a compact and efficient connection solution.
