| Country of Origin | India |
|---|---|
| Diameter | 1.91mm |
| Brand | onsemi |
| Height | 4.56mm |
| Length | 1.91mm |
| Model | 1N456ATR |
| Mount Type | Through Hole |
| Series | 1N456A |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-35 |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 500mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Small Signal |
| Peak Reverse Current Ir | 5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 4A |
| Maximum Forward Voltage Vf | 1V |
onsemi 1N456ATR is a small signal switching diode with a maximum continuous forward current rating of 500 mA and a peak reverse repetitive voltage of 30 V. Packaged in a DO-35 2-pin through hole form factor, this diode is engineered for discrete semiconductor applications requiring reliable switching performance.
This small signal diode features a maximum forward voltage of 1 V to optimize power efficiency and tolerates peak non-repetitive forward surge currents up to 4 A, making it suitable for transient conditions often seen in electronic circuitry. With a maximum operating temperature of 175°C, the device can endure demanding industrial and electronic environments.
Standardized physical dimensions with a length of 1.91 mm, diameter of 1.91 mm, and height of 4.56 mm facilitate straightforward layout and assembly on printed circuit boards. The diode's low peak reverse current of 5 μA ensures minimal leakage current, enhancing reliability for sensitive applications.
Commonly used in power and signal rectification circuits, the onsemi 1N456ATR diode supports various industrial, laboratory, electronics manufacturing, and HVAC control uses. Its small signal characteristics make it ideal for switching, signal modulation, and protective diode roles in electronic designs.
Small signal diode designed for through hole mounting. Package type is DO-35 with 2 pins. Maximum continuous forward current of 500 mA ensures moderate power handling. Peak reverse repetitive voltage of 30 V suitable for low-voltage circuits.
Maximum forward voltage of 1 V enhances efficiency in switching applications. Peak non-repetitive forward surge current up to 4 A allows tolerance to transient conditions. Maximum operating temperature of 175°C supports robust industrial environments.
Standard dimensions with length 1.91 mm, diameter 1.91 mm, and height 4.56 mm. Single diode configuration with 2-pin layout for easy PCB integration. Low peak reverse current of 5 μA minimizes leakage losses. Explore the extensive range of semiconductors and diodes in the Electronics & Electricals category at EnvMart to find compatible components for your project needs.
