Taiwan Semiconductor 1-Element Uni-Directional TVS Diode 1.5 kW Peak Pulse Power 2-Pin DO-214 SMCJ11A

Taiwan Semiconductor SMCJ11A 1-Element Uni-Directional TVS Diode is engineered for transient voltage suppression, providing an industrial-grade peak pulse power dissipation of 1.5 kW. The diode's uni-directional configuration ensures efficient surge protection in sensitive electronic circuits.

This TVS diode features a minimum breakdown voltage of 12.2 V and a maximum reverse stand-off voltage of 11 V, clamping surges at 18.2 V to prevent damage. It supports operation across a wide temperature range from -55°C to 150°C, making it suitable for demanding industrial, laboratory, and commercial environments.

The diode package is a compact DO-214 surface mount type with physical dimensions of 7.15 mm in length, 6.25 mm width, and 2.75 mm height. Its 2-pin design allows seamless PCB mounting and integration into electronic systems.

The SMCJ11A model provides high surge tolerance with a peak pulse current of 82.4 A, supported by a glass-passivated junction construction that enhances device reliability and longevity. It exhibits low incremental surge resistance and fast response time for critical circuit protection needs.

This diode meets the FBI standard and carries UL94V-0 flammability classification, ensuring safety and quality compliance for diverse applications including power management, automotive electronics (non-automotive standard), industrial control systems, and consumer electronics.

Key features include robust 1.5 kW surge handling, compact surface mount design, and precise electrical characteristics providing dependable transient voltage suppression. Uni-directional diode configuration for effective transient voltage suppression.

Clamping voltage of 18.2 V ensures circuit protection during surges. Minimum breakdown voltage of 12.2 V with a max reverse stand-off voltage of 11 V. Operates reliably in a temperature range from -55°C to 150°C. Compact physical dimensions of 7.15 mm length, 6.25 mm width, and 2.75 mm height.

Peak pulse current rating of 82.4 A for high surge tolerance. Glass-passivated junction construction enhances durability and performance. Fast response time suitable for sensitive electronics protection. Mount type: Surface mount for PCB integration.

2-pin configuration in a DO-214 package type. Explore Taiwan Semiconductor products and other high-performance TVS Diodes on EnvMart to enhance your electronic design projects.
