Wurth Elektronik WE-TPC 2811 Shielded Wirewound Surface Mount Inductor with Ferrite Core 0.82 μH ±35% 2A 74402800082

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik WE-TPC 2811 Shielded Wirewound Surface Mount Inductor with Ferrite Core 0.82 μH ±35% 2A 74402800082

Name: Wurth Elektronik WE-TPC 2811 Shielded Wirewound Surface Mount Inductor with Ferrite Core 0.82 μH ±35% 2A 74402800082
Brand: Wurth Elektronik
SKU: 373103
Price: 1.07 USD
Availability: InStock



Category Surface Mount Inductor Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Brand	Wurth Elektronik
Operating Temperature	- 40 to +125°C
Height	2.8mm
Length	2.8mm
Depth	1.1mm
Packaging	Tape & Reel
Series	WE-TPC
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-40°C
Core Material	Ferrite
Inductance	0.82μH
Package/Case	2811
Maximum DC Current	2A
Maximum DC Resistance	65mΩ
Inductance Tolerance	±35 %
Termination Style	Surface Mount
Maximum Self Resonant Frequency	180MHz
Inductor Construction	Wirewound
Automotive Standard	AEC-Q200
IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS, IEC 61249-2-21, IEC 60286-3	2013

Key Features

This inductor uses a ferrite core for efficient magnetic performance.
Its compact 2.8mm x 2.8mm x 1.1mm size suits surface mount PCB applications.
Designed for operation from -40°C to +125°C ensuring reliability under varied conditions.
Features magnetic shielding to reduce electromagnetic interference.
Complies with automotive standard AEC-Q200 and multiple industry approvals.
Offers a maximum DC resistance of 65mΩ for low power loss.
Packaged on tape and reel for automated assembly processes.
Suitable for portable power devices, DC/DC converters, embedded PCs, and telemetric applications.

Product Description

Wurth Elektronik 74402800082 is a shielded wirewound surface mount power inductor from the WE-TPC series, featuring a ferrite core with an inductance of 0.82 μH and a tolerance of ±35%. It supports a maximum DC current of 2 A and is optimized for high current capability in a compact 2.8 mm square design with a depth of 1.1 mm, ideal for space-constrained electronic applications.

The magnetic shielding minimizes electromagnetic interference, making it well-suited for sensitive portable power applications, including PDAs, digital cameras, PCMCIA cards, embedded PCs, and mobile data gathering systems that require stable and efficient power management.

Operating reliably across a temperature range from -40°C to +125°C, it meets automotive standard AEC-Q200 and holds approvals such as IPC/JEDEC J-STD-020E, JEDEC JS709B, REACH, RoHS, IEC 61249-2-21, and IEC 60286-3:2013, underscoring strict compliance to industry standards.

The inductor features surface mount termination style in a tape and reel package, facilitating efficient pick-and-place assembly. Its maximum DC resistance is 65 milliohms, contributing to low power dissipation during operation.

This product provides high current, magnetically shielded power inductance. Compact footprint and thickness enable integration in small electronic assemblies. Robust operating temperature range supports demanding industrial and automotive environments.

Compliant with multiple international standards and environmental regulations. Manufactured in China with quality assurance practices. Available in tape and reel packaging for high volume SMT applications. Explore more Surface Mount Inductors and components on EnvMart for diverse industrial, automotive, and electronic manufacturing needs.
