STMicroelectronics NPN Power Transistor 1 A 60 V TO-220 Package Single Configuration TIP29A

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics NPN Power Transistor 1 A 60 V TO-220 Package Single Configuration TIP29A

Name: STMicroelectronics NPN Power Transistor 1 A 60 V TO-220 Package Single Configuration TIP29A
Brand: STMicroelectronics
SKU: 372226
Price: 0.54 USD
Availability: InStock



Category Power Transistors Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Brand	STMicroelectronics
Height	28.9mm
Length	10.53mm
Model	TIP29A
Width	4.83mm
Mount Type	Through Hole
Maximum Operating Temperature	150°C
Package Type	TO-220
Minimum Operating Temperature	0°C
Pin Count	3
Maximum Collector Emitter Voltage Vceo	60V
Minimum DC Current Gain hFE	15
Transistor Polarity	NPN
Maximum Emitter Base Voltage VEBO	5V
Maximum Collector Base Voltage VCBO	60V
Maximum Power Dissipation Pd	30W
Maximum DC Collector Current Idc	1A
Transistor Configuration	Single
STMicroelectronics TIP29A Transistor, 1 A NPN, 60 V, 3-Pin TO-220Brand	STMicroelectronics

Key Features

This transistor has a maximum power dissipation of 30 watts.
Designed with a single transistor configuration in NPN polarity.
It has a minimum DC current gain (hFE) of 15 ensuring reliable amplification.
Operating temperature range spans from 0°C to a maximum of 150°C.
Package mounting is through-hole type suitable for various PCB applications.
Package dimensions include height 28.9 mm, width 4.83 mm, and length 10.53 mm.
Maximum collector base voltage and emitter base voltage are 60 V and 5 V respectively.
The transistor is compliant with industry standards, though no specific certifications are noted.

Product Description

STMicroelectronics TIP29A is an NPN power transistor designed for electronic components, power, and connector applications requiring up to 1 ampere collector current and 60 volts collector-emitter voltage.

This device is housed in a TO-220 package with a through-hole mount type, facilitating easy installation in various industrial and electronic circuits. It features a maximum power dissipation rating of 30 watts, suitable for moderate power switching and amplification tasks in both commercial and industrial environments.

The transistor configuration is single NPN, with minimum DC current gain of 15, making it reliable for general-purpose power applications. It supports operational temperatures from 0°C up to 150°C, compatible with a wide range of industrial ambient conditions.

Package dimensions are 28.9 mm in height, 4.83 mm in width, and 10.53 mm in length. The device includes a 3-pin configuration essential for typical transistor circuit implementations.

This transistor has a maximum DC collector current of 1 A. Collector-emitter voltage is rated for a maximum of 60 V. The TO-220 package type ensures efficient heat dissipation. Mounting is suited for through-hole PCB assembly.

The transistor polarity is NPN for positive switching applications. Widely used in industrial, manufacturing, laboratory, and electronic design sectors. Set includes 1-piece transistor ready for integration into power circuits.

Choose STMicroelectronics TIP29A for reliable power transistor performance in a compact, industry-standard package offering excellent durability and wide operating conditions. Explore more semiconductor and power transistor solutions in the Electronics & Electricals category at EnvMart for your industrial and commercial electronic project needs.
