onsemi Schottky Diode 70 V 15 mA 3-Pin SOT-23 BAS70-04LT1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi Schottky Diode 70 V 15 mA 3-Pin SOT-23 BAS70-04LT1G

Name: onsemi Schottky Diode 70 V 15 mA 3-Pin SOT-23 BAS70-04LT1G
Brand: onsemi
SKU: 371557
Price: 0.04 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.01mm
Length	3.04mm
Model	BAS70-04LT1G
Width	1.4mm
Mount Type	Surface
Series	BAS70-04L
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Pin Count	3
Automotive Standard	AEC-Q101
Maximum Continuous Forward Current If	15mA
Peak Reverse Repetitive Voltage Vrrm	70V
Diode Configuration	Series
Rectifier Type	Schottky
Peak Reverse Current Ir	10μA
Peak Non-Repetitive Forward Surge Current Ifsm	100mA
Maximum Forward Voltage Vf	1V

Key Features

This diode supports a maximum continuous forward current of 15 mA.
The peak reverse repetitive voltage rating is 70 V.
It features a compact 3-pin SOT-23 package suitable for automated assembly.
Maximum forward voltage drop is 1 V, enhancing efficiency in circuits.
Operating temperature range spans from -55°C to 150°C, ensuring reliability in demanding environments.
The diode offers a peak non-repetitive forward surge current of 100 mA.
An automotive standard AEC-Q101 qualified product suitable for automotive and industrial use.
The physical dimensions are 3.04 mm length, 1.4 mm width, and 1.01 mm height.

Product Description

onsemi BAS70-04LT1G is a Schottky Barrier Diode featuring a low forward voltage drop and minimal reverse current, optimized for high-frequency switching and rectification in compact surface mount applications.

This diode is presented in a 3-pin SOT-23 package, ideal for automated PCB assembly and space-constrained electronic designs. The device operates reliably across a temperature range from -55°C to 150°C, making it suitable for automotive and industrial applications where thermal stability is critical.

With a peak reverse voltage of 70 V and maximum continuous forward current of 15 mA, the BAS70-04LT1G excels in low voltage rectification, polarity protection, and freewheeling applications.

Maximum continuous forward current of 15 mA ensures steady performance under rated loads. Peak reverse current limited to 10 μA minimizes leakage and power loss. Low forward voltage (1 V max) facilitates efficient power conversion.

Compliant with automotive AEC-Q101 standards, ensuring durability and safety in automotive electronics. This diode's small footprint and epoxy molded case reduce weight to approximately 11.7 mg, ideal for lightweight designs.

Designed with Pb-free construction aligned with environmental regulations. Its robust barrier metal technology enables an excellent forward voltage-reverse current characteristic balance.

The BAS70-04LT1G is suitable for electronic manufacturing sectors including consumer electronics, automotive systems, industrial controls, and telecommunications equipment requiring efficient Schottky diode performance.

Explore the broad range of semiconductors and Schottky diodes available on EnvMart to enhance your electronic system designs.

Explore more products in our Schottky Diodes & Rectifiers category.
