onsemi Schottky Diode 100 V 10 A Surface Mount TO-263 Package 3-Pin D2PAK

onsemi MBRB20H100CTT4G is a high-performance Schottky diode designed for power rectification applications. Packaged in a TO-263 D2PAK surface mount style, it is well-suited for compact electronic devices requiring efficient and reliable power conversion.

This diode supports a continuous forward current of up to 10 amperes and a peak reverse voltage rating of 100 volts, making it suitable for a range of power supply and automotive electronics uses. The common cathode Schottky barrier design ensures low forward voltage drop of 770 mV, contributing to reduced power loss and improved efficiency in circuits.

The device is automotive qualified under the AEC-Q101 standard, signifying robust reliability under harsh environmental conditions typical in automotive applications.

With a compact footprint - measuring approximately 10.29 mm in length, 9.65 mm in height, and 4.83 mm in width - and 3-pin configuration, installation on circuit boards is straightforward, supporting high-density electronic assemblies.

The MBRB20H100CTT4G diode can withstand peak non-repetitive forward surge currents of 250 amperes, accommodating transient current spikes commonly encountered in power electronics.

Its operating temperature up to 175°C allows it to function reliably in demanding industrial, automotive, and consumer electronic environments requiring heat tolerance. This Schottky diode supports a maximum continuous forward current of 10 amperes.

It features a peak reverse repetitive voltage rating of 100 volts. The diode configuration is common cathode with a low forward voltage drop of 770 millivolts. This device is automotive qualified to AEC-Q101 standard, ensuring reliability in vehicle systems.

The diode has a compact TO-263 package with dimensions approximately 10.29 mm length, 9.65 mm height, and 4.83 mm width. Peak non-repetitive forward surge current capability reaches 250 amperes momentarily. Operating temperature extends to a high 175 degrees Celsius for robust industrial performance.

Pin count is 3, suitable for various power and rectifier applications. The diode’s peak reverse current is low at 6 milliamperes, enhancing efficiency. The device is designed for surface mount applications in electronic assemblies.

This Schottky diode is commonly used in power supply circuits, automotive electronics, power management modules, and discrete semiconductor assemblies requiring fast switching and low forward voltage drop for improved efficiency and reduced heat dissipation.
