Molex Mini-Fit Sr Series Right Angle Through Hole PCB Header, 4 Contacts, 10 mm Pitch, 1 Row, Shrouded 42820-4223

Free Delivery in India | Lowest Global Shipping Charges

Molex Mini-Fit Sr Series Right Angle Through Hole PCB Header, 4 Contacts, 10 mm Pitch, 1 Row, Shrouded 42820-4223

Name: Molex Mini-Fit Sr Series Right Angle Through Hole PCB Header, 4 Contacts, 10 mm Pitch, 1 Row, Shrouded 42820-4223
Brand: Molex
SKU: 368712
Price: 12.84 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	Mexico
Voltage	600V
Brand	Molex
Orientation	Right Angle
Current	50A
Mount Type	Through Hole
Housing Material	Thermoplastic
Contact Material	Brass
Series	Mini-Fit Sr
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	10mm
Contact Plating	Gold
Number of Contacts	4
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
428xx-x2x2	Tin plated contact area
428xx-x2x3	Gold plated contact area
428xx-x21x	1.57 mm nominal PCB thickness
428xx-x22x	2.36 mm nominal PCB thickness
428xx-x23x	3.18 mm nominal PCB thickness
428xx-x24x	6.35 mm nominal PCB thickness

Key Features

Provides a current rating of up to 50A for high power applications.
Features brass contacts with gold plating to ensure reliable conductivity.
Constructed with thermoplastic housing for durability and insulation.
Operates reliably between -40°C and 105°C temperature range.
Designed with 1 row and right-angle orientation for mounting flexibility.
Through hole mount type ensures stable PCB attachment.
Connector system supports wire-to-board connection schemes.
Termination type is solder to secure connections.

Product Description

Molex 42820-4223 Mini-Fit Sr Series Right Angle Through Hole PCB Header is a high-performance, shrouded male connector featuring 4 contacts arranged in a single row with 10 mm pitch. Designed for wire-to-board applications, this connector supports current up to 50A and voltage up to 600V, making it suitable for demanding industrial, manufacturing, and electronic assembly environments.

The housing is made of durable thermoplastic material that ensures electrical insulation and mechanical strength. Brass contacts with gold plating provide excellent conductivity and corrosion resistance. The right angle orientation and through hole mounting type facilitate secure attachment and compact PCB design.

This connector operates reliably across a broad temperature range from -40°C to 105°C, ideal for various harsh conditions. The solder termination enhances mechanical stability and electrical integrity during usage.

Typical applications include power connectors in industrial control equipment, consumer electronics, and custom PCB assemblies. Its wire-to-board connector system ensures compatibility with Mini-Fit Sr receptacle housings for versatile design integration.

Provides a current rating of up to 50A for high power applications. Features brass contacts with gold plating for reliable conductivity. Constructed with thermoplastic housing for durability and insulation. Operates reliably between -40°C and 105°C temperature range.

Designed with 1 row and right-angle orientation for mounting flexibility. Through hole mount type ensures stable PCB attachment. Connector system supports wire-to-board connection schemes. Termination type is solder for secure connections.

Voltage rating is up to 600V for industrial use cases. Manufactured in Mexico under strict quality standards.

Molex Mini-Fit Sr Series connectors are an excellent choice for reliable power and signal transmission in demanding industrial, electronic components, HVAC, manufacturing, and commercial applications. Explore the complete Mini-Fit Sr Series range on EnvMart for compatible connectors and accessories.

Explore more products in our PCB Headers category.
