Molex Mini-Fit Sr Series Straight Through Hole PCB Header, 2 Contact, 10 mm Pitch, 1 Row, Shrouded 42819-2213

Free Delivery in India | Lowest Global Shipping Charges

Molex Mini-Fit Sr Series Straight Through Hole PCB Header, 2 Contact, 10 mm Pitch, 1 Row, Shrouded 42819-2213

Name: Molex Mini-Fit Sr Series Straight Through Hole PCB Header, 2 Contact, 10 mm Pitch, 1 Row, Shrouded 42819-2213
Brand: Molex
SKU: 368699
Price: 7.69 USD
Availability: InStock



Category PCB Headers Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	600V
Brand	Molex
Orientation	Straight
Current	50A
Mount Type	Through Hole
Housing Material	Thermoplastic
Contact Material	Brass
Series	Mini-Fit Sr
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	-40°C
Number of Rows	1
Pitch	10mm
Contact Plating	Gold
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board
428xx-x2x2	Tin plated contact area
428xx-x2x3	Gold plated contact area
428xx-x21x	1.57 mm nominal PCB thickness
428xx-x22x	2.36 mm nominal PCB thickness
428xx-x23x	3.18 mm nominal PCB thickness
428xx-x24x	6.35 mm nominal PCB thickness

Key Features

This Mini-Fit Sr Series PCB Header supports up to 50A current rating.
Features thermoplastic housing material for reliable insulation.
Contact plating uses gold for optimal conductivity and corrosion resistance.
Designed with 10 mm pitch and a single row for compact PCB mounting.
Suitable for operating temperatures from -40°C to 105°C without performance loss.
Ensures secure solder termination with male contact gender.
Wire-to-Board connector system supports robust electrical connections.
Through Hole mount type facilitates stable mechanical and electrical bonding on PCBs.

Product Description

Molex 42819-2213 Mini-Fit Sr Series Straight Through Hole PCB Header is a high-quality, 2-contact electrical connector designed for wire-to-board applications. It features a 10 mm pitch and a single row of male contacts with a shrouded construction to protect connections and improve durability. The connector housing is made from thermoplastic to ensure insulation and withstand operating temperatures ranging from -40°C to 105°C.

The contacts are brass with gold plating, delivering excellent conductivity and resistance to corrosion which is essential in demanding industrial environments. The connector is intended for through-hole mounting, providing stable mechanical strength and reliable solder connections to printed circuit boards.

This Mini-Fit Sr Series header supports a current rating of up to 50A and voltage up to 600V, making it suitable for power electronics requiring robust and safe connection solutions. The connector's design includes metal PCB retention clips and pre-assembled male contacts to expedite assembly and improve production efficiency.

This PCB header is commonly used in industrial, manufacturing, automation, and commercial electronic products offering critical wire-to-board connectivity. Its compatibility with Mini-Fit Sr cable receptacle housings provides versatility in complex wiring harnesses.

This Mini-Fit Sr Series PCB Header supports up to 50A current rating. Features thermoplastic housing material for reliable insulation. Contact plating uses gold for optimal conductivity and corrosion resistance. Designed with 10 mm pitch and a single row for compact PCB mounting.

Suitable for operating temperatures from -40°C to 105°C without performance loss. Ensures secure solder termination with male contact gender. Wire-to-Board connector system supports robust electrical connections. Through Hole mount type facilitates stable mechanical and electrical bonding on PCBs.
