onsemi PNP Bipolar Transistor 1.5 A 80 V 4-Pin Surface Mount SOT-223 BCP53-16T3G

Free Delivery in India | Lowest Global Shipping Charges

onsemi PNP Bipolar Transistor 1.5 A 80 V 4-Pin Surface Mount SOT-223 BCP53-16T3G

Name: onsemi PNP Bipolar Transistor 1.5 A 80 V 4-Pin Surface Mount SOT-223 BCP53-16T3G
Brand: onsemi
SKU: 368299
Price: 0.24 USD
Availability: InStock



Category Bipolar Transistors Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.75mm
Length	6.7mm
Model	BCP53-16T3G
Width	3.7mm
Mount Type	Surface
Series	BCP53
Maximum Operating Temperature	150°C
Package Type	SOT-223
Minimum Operating Temperature	-65°C
Pin Count	4
Maximum Collector Emitter Voltage Vceo	-80V
Minimum DC Current Gain hFE	25
Transistor Polarity	PNP
Maximum Emitter Base Voltage VEBO	5V
Maximum Collector Base Voltage VCBO	100V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	1.5W
Maximum DC Collector Current Idc	-1.5A
Transistor Configuration	Single
Maximum Transition Frequency ft	50MHz
STMicroelectronics STN9360 Transistor, -500 mA PNP, -600 V, 3-Pin SOT-223Brand	STMicroelectronics

Key Features

This transistor operates with a maximum power dissipation of 1.5 W.
It features a maximum collector base voltage of 100 V and a maximum emitter base voltage of 5 V.
The device has a minimum DC current gain (hFE) of 25.
Its maximum transition frequency is 50 MHz, suitable for moderate frequency applications.
The package type is SOT-223 with surface mount technology for compact assembly.
The transistor configuration is single and is polarized as PNP.
Operating temperature range is wide from -65°C to 150°C for industrial robustness.
The package dimensions are 6.7 mm length, 3.7 mm width, and 1.75 mm height.

Product Description

onsemi BCP53-16T3G PNP Bipolar Transistor provides robust performance with a maximum DC collector current of 1.5 A and collector-emitter voltage rating of 80 V, housed in a 4-pin SOT-223 surface mount package. This transistor is well-suited for various industrial, automotive, and electronic applications requiring reliable switching and amplification.

Equipped with a maximum power dissipation of 1.5 W, it supports safe operation under demanding electrical loads. Its maximum collector base voltage of 100 V and emitter base voltage of 5 V provide ample voltage margins for transistor operation. The minimum DC current gain of 25 and transition frequency of 50 MHz enable effective signal amplification and switching at moderate frequencies.

The compact SOT-223 package allows for surface mounting on printed circuit boards, facilitating miniaturized and automated assembly processes. Its operational temperature range from -65°C to 150°C ensures excellent reliability under extreme environmental conditions common in automotive and industrial applications.

Compliant with automotive standard AEC-Q101, the BCP53-16T3G is qualified for automotive electronics, guaranteeing durability and performance reliability in safety-critical environments.

This general-purpose PNP bipolar transistor is ideal for switching, amplification, and signal processing in power management circuits. The 4-pin architecture supports flexible circuit integration while maintaining compact form factor.

The SOT-223 surface mount package provides efficient heat dissipation and easy PCB integration. Its wide voltage and temperature ratings extend its usability in automotive, industrial, and consumer electronics. Compliance with AEC-Q101 automotive standard ensures quality and ruggedness for automotive electronics systems.

Discover more onsemi Bipolar Transistors and other semiconductor components suited for electronic designs in industrial, automotive, and consumer electronics sectors on EnvMart.
