onsemi PNP Transistor, Maximum DC Collector Current -1.5 A, Maximum Collector Emitter Voltage -80 V, 4-Pin BCP53-16T3G

onsemi BCP53-16T3G is a high-quality PNP transistor designed for various electronic applications requiring a maximum DC collector current of -1.5 A and collector emitter voltage of -80 V. Its 4-pin surface mount SOT-223 package facilitates easy integration in compact PCB designs.

This transistor features a single transistor configuration, optimized for general-purpose amplification and switching tasks. Its robust power dissipation of 1.5 W allows it to operate efficiently within demanding environments.

The device supports a broad operating temperature range from -65°C to 150°C, making it suitable for industrial, automotive, and commercial electronics where temperature resilience is critical. Additionally, the product complies with AEC-Q101 automotive standards, ensuring reliability under stringent automotive requirements.

With dimensions of 6.7 mm in length, 3.7 mm in width, and 1.75 mm in height, the transistor is compact enough for space-constrained applications. It also offers a maximum transition frequency of 50 MHz, enabling high-speed electronic switching.

The minimum DC current gain of 25 ensures effective amplification performance. Its maximum collector base voltage is rated at 100 V, and maximum emitter base voltage at 5 V, providing versatility in circuit design.

Designed for surface mount applications in electronic circuits. Single transistor configuration suitable for general purpose use. Maximum power dissipation of 1.5 W for reliable performance. Operating temperature range from -65°C to 150°C ensures durability.

Automotive standard compliant with AEC-Q101 for quality assurance. Compact dimensions of 6.7 mm length, 3.7 mm width, and 1.75 mm height. Maximum transition frequency of 50 MHz for high-speed switching. Minimum DC current gain (hFE) of 25 providing effective amplification.

This transistor is suitable for use in industrial, automotive, commercial, and electronic manufacturing sectors, facilitating efficient switching and amplification tasks. Ideal for powering and signal control circuits within various electronic devices.
