Samtec TSW Series Straight Through Hole Pin Header 100 Contacts 2.54 mm Pitch 2 Row Unshrouded TSW-150-06-L-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 7.6A |
| Model | TSW-150-06-L-D |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 100 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 2.41mm |
| Mating Pin Length | 2.67mm |
Key Features
- Supports a current rating of 7.6 A for reliable electrical performance.
- Features a glass filled polyester housing for durability and insulation.
- Comprises 2 rows with an unshrouded, straight orientation for easy mounting.
- Contacts are made of phosphor bronze with gold plating for corrosion resistance.
- Designed for through hole mounting with solder termination for secure fixing.
- Operates within a temperature range of -55°C to 125°C accommodating harsh environments.
- Includes 2.41 mm tail pin length and 2.67 mm mating pin length for precise connectivity.
Product Description
Samtec TSW-150-06-L-D TSW Series Straight Through Hole Pin Header is a high-quality 100-contact connector designed for PCB board-to-board and wire-to-board applications. It features a 2.54 mm pitch and a robust black glass filled polyester housing that ensures long-lasting insulation and mechanical stability.
The header contains phosphor bronze contacts with gold plating, delivering excellent electrical conductivity and resistance to corrosion. This component is unshrouded and has a straight orientation with 2 rows of pins, making it suitable for through hole solder mounting in various electronics assemblies.
Rated for a maximum current of 7.6 A and voltage up to 550 V, the TSW-150-06-L-D supports demanding power requirements in industrial, electronic, and communication systems. It operates reliably in temperatures ranging from -55°C to 125°C, making it capable of functioning in harsh environmental conditions.
The pin header provides precise mechanical interfacing with a tail pin length of 2.41 mm and mating pin length of 2.67 mm, ensuring secure connections with compatible sockets. Supports 7.6 A current rating providing stable electrical performance.
Durable glass filled polyester housing ensures insulation and mechanical strength. Phosphor bronze, gold-plated contacts offer corrosion resistance and conductivity. Unshrouded and straight orientation with 2 rows for flexible mounting options.
Through hole mount type with solder termination for secure assembly. Wide operating temperature range from -55°C to 125°C for diverse applications. Voltage rating of 550 V for versatile electronic use. Tail and mating pin lengths optimized for precise connectivity.
This pin header is ideal for use in industrial electronics, manufacturing equipment, test instruments, and communication devices where reliable board interconnections are critical. It is compatible with various Samtec sockets such as BCS, CES, SLW, SSM, SSQ, and SSW.
Browse Samtec connectors and PCB Headers at EnvMart to find matching components and enhance your project’s connectivity solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating of this model is 7.6 A, ensuring reliable electrical performance.
It has a voltage rating of 550 V, making it suitable for various electronic applications.
The contacts are made of phosphor bronze and are gold plated for enhanced corrosion resistance and conductivity.
This model features a pitch of 2.54 mm, which is standard for many PCB applications.
It operates within a temperature range of -55°C to 125°C, accommodating harsh environments.
This pin header comprises 100 contacts, allowing for multiple connections in a compact design.
It is designed for through hole mounting with solder termination, ensuring secure assembly.
The tail pin length is 2.41 mm, optimized for precise connectivity with compatible sockets.
The housing is made from glass filled polyester, providing durability and insulation.
It has a straight orientation and is unshrouded, allowing for flexible mounting options.
It is compatible with various Samtec sockets including BCS, CES, SLW, SSM, SSQ, and SSW.
This model is suitable for board-to-board and wire-to-board applications in industrial electronics, manufacturing equipment, and communication devices.
