Samtec TSM Series Right Angle Surface Pin Header 25 Contacts 2.54 mm Pitch 1 Row Unshrouded TSM-125-02-L-SH
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 475V |
| Brand | Samtec |
| Orientation | Right Angle |
| Current | 7A |
| Model | TSM-125-02-L-SH |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | TSM |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 25 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Mating Pin Length | 8.13mm |
Key Features
- Features a liquid crystal polymer housing for durability and heat resistance.
- Phosphor bronze contacts plated with 0.25μm gold for excellent conductivity and corrosion resistance.
- Operates reliably within a temperature range of -55°C to 125°C.
- Designed for board-to-board and wire-to-board connectivity with surface mounting.
- Supports a maximum current rating of 7A and a voltage rating of 475V.
- Terminated by soldering; contact gender is male with a mating pin length of 8.13 mm.
- Offers a right angle orientation for flexible PCB assembly configurations.
Product Description
Samtec TSM-125-02-L-SH is a high-quality right angle surface mount pin header designed for reliable PCB interconnections in industrial and electronic applications. Featuring 25 contacts arranged in a single row with a precise 2.54 mm pitch, this unshrouded header provides robust electrical connectivity with phosphor bronze contacts plated in 0.25μm gold for enhanced corrosion resistance and conductivity.
The housing is constructed from liquid crystal polymer, providing excellent durability and stability at elevated temperatures ranging from -55°C to 125°C, making it suitable for demanding environments. This component supports a current capacity of 7A and withstands up to 475 volts, ensuring safe and efficient board-to-board or wire-to-board connections.
The product is surface mounted with a solder termination type and incorporates male contacts with an 8.13 mm mating pin length, optimized for right angle PCB designs. It is ideal for use in industrial equipment, communication devices, consumer electronics, and other commercial electronic assemblies requiring reliable signal and power transmission.
Liquid crystal polymer housing delivers mechanical strength and thermal stability. Phosphor bronze contacts with gold plating guarantee electrical performance and durability. Right angle orientation enhances PCB layout flexibility.
Designed for surface mount technology (SMT) for automated PCB assembly lines. Wide operating temperature range suits various industrial and commercial environments. Supports high current and voltage levels for demanding electrical applications.
Unshrouded design facilitates ease of inspection and maintenance.
This Samtec TSM Series header is a critical component in electronics manufacturing, ensuring consistent connectivity and longevity. Browse the PCB Connectors category on EnvMart for similar high-quality interconnect solutions from leading manufacturers.
Explore more products in our PCB Headers category.
