Infineon N-Channel IGBT Module 450 A 1200 V 3-Pin 62 mm Module Clamp FF450R12KT4HOSA1

Infineon FF450R12KT4HOSA1 is an N-Channel Insulated Gate Bipolar Transistor (IGBT) module designed for demanding industrial power conversion applications. It features a maximum collector-emitter voltage of 1200 volts and supports a continuous collector current of up to 450 amperes, making it suitable for high-load operations requiring robust high-voltage switching.

The device is housed in a compact 62 mm clamp-mount module, measuring 106.4 mm in length, 61.4 mm in width, and 30.9 mm in height. It features a 3-pin configuration which simplifies high-current connections and ensures reliable assembly in industrial setups. The module supports a maximum power dissipation of 2400 watts to manage high thermal stress during operation.

Operating temperatures range from -40 °C up to 150 °C, enabling use in demanding environments with significant thermal variation. The gate-emitter voltage is protected up to 20 volts, safeguarding the module’s gate drive and enhancing reliability in switching circuits.

This IGBT module complies with UL (E83335) standards, ensuring compliance with recognized safety assessments. However, it is not rated for automotive standards, focusing its use on industrial and commercial sectors.

Designed for clamp mounting in a 62 mm package for secure installation. Supports applications with extreme ambient temperature ranges from -40°C to 150°C. N-channel topology requiring positive gate drive for switching. High continuous current capacity of 450 amperes suitable for heavy industrial loads.

Collector-emitter saturation voltage of 2.15V minimizes conduction losses. Thermally robust with maximum power dissipation of 2400 watts. Widely used in industrial motor drives, renewable energy inverters, traction converters for rail vehicles, welders, and induction heaters.

This Infineon IGBT Module is an essential component for high-power electronics, offering reliable performance and efficient switching in demanding industrial applications. Browse the Electronics & Electricals category for more semiconductor and power modules on EnvMart.
