| Country of Origin | China |
|---|---|
| Brand | DiodesZetex |
| Height | 1.1mm |
| Length | 3mm |
| Model | BAS70-06-7-F |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | BAS70-06 |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 70mA |
| Peak Reverse Repetitive Voltage Vrrm | 70V |
| Diode Configuration | Common Anode |
| Rectifier Type | Switching |
| Peak Reverse Current Ir | 100nA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 100mA |
| Maximum Forward Voltage Vf | 1V |
| Peak Reverse Recovery Time trr | 5ns |
DiodesZetex BAS70-06-7-F is a surface mount switching diode designed for electronic semiconductor applications requiring fast switching and low voltage drop characteristics.
Featuring a compact 3-pin SOT-23 package with precise dimensions of 3 mm length, 1.4 mm width, and 1.1 mm height, this diode offers excellent space efficiency for modern PCB layouts.
It supports a continuous forward current up to 70 mA and can withstand peak surges of 100 mA while maintaining a low maximum forward voltage of 1 V which minimizes power loss during operation.
The diode has a peak reverse repetitive voltage rating of 70 V and a peak reverse current of only 100 nA, providing robust electrical performance and improved efficiency in switching circuits.
With an operating temperature range from -55°C to 125°C and a fast peak reverse recovery time of 5 nanoseconds, the BAS70-06-7-F is suitable for high-frequency switching applications in telecommunications, power supplies, and signal processing devices.
This component meets the stringent automotive standard AEC-Q101, ensuring enhanced reliability and durability in automotive and industrial environments. Surface mount type supports automated assembly. Compact 3-pin SOT-23 package for space-saving designs.
70 mA maximum continuous forward current rating. 70 V peak reverse repetitive voltage rating. Low maximum forward voltage drop of 1 V. Wide operating temperature range from -55°C to 125°C. Fast peak reverse recovery time of 5 ns.
Common anode configuration. Meets AEC-Q101 automotive standard. Manufactured in China. This switching diode is widely used in industrial electronics, telecommunications, automotive electronic circuits, and general semiconductor applications.
Explore more products in the Schottky Diodes & Rectifiers category to find compatible components and accessories for your designs on EnvMart.
