| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 2.1mm |
| Length | 4.6mm |
| Model | B130-13-F |
| Width | 2.92mm |
| Mount Type | Surface |
| Series | B130 |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AC |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | FBI |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 10mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 500mV |
DiodesZetex B130-13-F Schottky Diode is a reliable semiconductor component designed for surface mounting in electronic circuits. Featuring a DO-214AC package, this diode supports a maximum continuous forward current of 1 ampere and a peak reverse repetitive voltage of 30 volts, ensuring effective rectification and protection in power applications.
This component is well suited for industrial, automotive, consumer electronics, and power supply applications that require high efficiency and low forward voltage drop. The diode’s single configuration provides straightforward circuit integration with minimal losses.
The device operates reliably over a broad temperature range from -65°C up to 150°C, making it suitable for harsh thermal environments. Its small physical size, with a length of 4.6 mm, width of 2.92 mm, and height of 2.1 mm, allows for compact PCB layouts and high-density mounting.
Key features include a low maximum forward voltage of 500 millivolts, a peak reverse current of only 10 milliamperes, and a peak forward surge current capability of 30 amperes. The product is compliant with FBI standards for quality assurance.
This diode is supplied in tape and reel format, facilitating efficient automated placement during manufacturing and assembly processes. Suitable for electronics manufacturing, power rectification, voltage clamping, and protection circuits in diverse industrial sectors.
Maximum continuous forward current is 1 ampere. Peak reverse repetitive voltage rating of 30 volts. Single diode configuration. Low forward voltage drop of 500 mV. Operating temperature range from -65°C to 150°C. Compact DO-214AC surface mount package.
Peak reverse current of 10 mA. 30 A peak non-repetitive forward surge current. FBI quality standard compliance. Supplied on tape and reel for automated assembly. Explore more Schottky Diodes & Rectifiers in EnvMart for industrial and electronic design needs.
