DiodesZetex 100 V 2 A Schottky Diode Surface Mount DO-214AA Package B1100LB-13-F

Free Delivery in India | Lowest Global Shipping Charges

DiodesZetex 100 V 2 A Schottky Diode Surface Mount DO-214AA Package B1100LB-13-F

Name: DiodesZetex 100 V 2 A Schottky Diode Surface Mount DO-214AA Package B1100LB-13-F
Brand: DiodesZetex
SKU: 363505
Price: 0.13 USD
Availability: InStock



Category Schottky Diodes & Rectifiers Brand DiodesZetex Condition New

Specifications

Country of Origin	India
Brand	DiodesZetex
Height	2.3mm
Length	4.57mm
Model	B1100LB-13-F
Width	3.94mm
Mount Type	Surface
Series	B1100
Maximum Operating Temperature	175°C
Package Type	DO-214AA
Minimum Operating Temperature	-65°C
Standards/Approvals	FBI
Pin Count	2
Maximum Continuous Forward Current If	2A
Peak Reverse Repetitive Voltage Vrrm	100V
Diode Configuration	Single
Rectifier Type	Schottky
Peak Reverse Current Ir	5mA
Peak Non-Repetitive Forward Surge Current Ifsm	50A
Maximum Forward Voltage Vf	750mV

Key Features

This diode features a maximum continuous forward current rating of 2 amperes.
It has a peak reverse repetitive voltage of 100 volts suitable for various power applications.
The forward voltage drop is low at a maximum of 750 millivolts, enhancing efficiency.
Designed to operate in temperatures from -65°C up to 175°C.
It includes a peak non-repetitive forward surge current rating of 50 amperes.
The diode has a 2-pin configuration with a single diode design type.
Compact dimensions with a length of 4.57 mm, width of 3.94 mm, and height of 2.3 mm enable easy PCB integration.
Package type DO-214AA supports surface mounting for automated assembly processes.

Product Description

DiodesZetex B1100LB-13-F is a high-performance Schottky diode suitable for semiconductor applications requiring low forward voltage drop and high reliability. Housed in a surface mount DO-214AA package, this diode is designed to efficiently conduct current with a maximum continuous forward current rating of 2 amperes and a peak reverse repetitive voltage of 100 volts.

Its low maximum forward voltage of 750 millivolts reduces power loss and heat generation, making it ideal for power rectification in industrial, electronic, and power supply applications. The diode supports a peak non-repetitive forward surge current up to 50 amperes, ensuring robustness under transient load conditions.

The device operates reliably within a wide temperature range from -65°C to 175°C, which is beneficial for harsh environments such as industrial or manufacturing electronics. Its compact size, with precise dimensions of 4.57 mm length, 3.94 mm width, and 2.3 mm height, aids in space-efficient PCB layouts and automated surface mount assembly processes.

This Schottky diode features a standard 2-pin single diode configuration and is built to comply with FBI standards for enhanced quality assurance. While it is not certified for automotive use, its attributes make it suitable for various electronic component power conversion and switching applications.

Maximum continuous forward current of 2A. Peak reverse repetitive voltage of 100V. Low maximum forward voltage of 750mV. Operating temperature range from -65°C to 175°C. Peak surge current rating of 50A. Surface mount DO-214AA package type.

Compact size: 4.57 mm x 3.94 mm x 2.3 mm. Single diode, 2-pin configuration. FBI standard compliance for quality. Not designed for automotive uses.

This diode is widely used in semiconductor, industrial electronics, and power & connectors sectors for applications including rectification, power management, and electronic circuit design. EnvMart offers an extensive range of Schottky diodes for diverse power electronics needs.
