onsemi Bridge Rectifier 400 V 50 A Surface Mount SDIP 4-Pin Single DF04S

onsemi DF04S Bridge Rectifier is a high-quality discrete semiconductor device with a single-phase configuration designed for efficient rectification in electronic circuits. It features a surface mount SDIP package with a compact form factor measuring 8.51 mm in length, 6.5 mm in width, and 2.6 mm in height, making it well-suited for PCB assembly.

This bridge rectifier supports a peak reverse repetitive voltage (Vrrm) of 400 V and a forward current (If) of 1.5 A, enabling it to handle moderate power electronic requirements. Its peak non-repetitive forward surge current (Ifsm) of 50 A ensures robust performance under surge conditions, making it suitable for industrial, laboratory, and commercial electronic applications.

Operating reliably between temperatures of -55°C and 150°C, the DF04S is engineered for durability even in challenging environments. The device utilizes a glass passivated chip junction technology that provides low DC reverse current, thus minimizing power loss and improving overall efficiency.

The 4-pin single configuration and surface mount design optimize integration into compact electronic systems requiring efficient power conversion from AC to DC signals. It is ideal for use in power supply circuits, industrial control systems, and other semiconductor-based electronic devices.

Compact SDIP surface-mount package for easy PCB integration. 400 V peak reverse repetitive voltage for high voltage applications. 1.5 A forward current rating for moderate load capacity. High operating temperature limit of 150°C for harsh environments.

Glass passivated chip junction technology ensures low leakage current. Peak surge current of 50 A provides transient resistance. Operating temperature range from -55°C to 150°C. 4-pin single-phase bridge rectifier configuration.

Suitable for industrial, laboratory, and commercial applications. Reliable and durable construction for extended service life.

This onsemi bridge rectifier DF04S is a dependable semiconductor component essential for power conversion in a wide range of electronics and electrical systems. It supports design requirements in industrial automation, power management, and semiconductor device manufacturing. Browse the Electronics & Electricals category on EnvMart for more discrete semiconductors and Bridge Rectifier products to find compatible components for your projects.
